Automatic mm / inch conversion · Core engineering specifications
| Overall desktop dimensions | 2400 x 1150 x 760 mm | |
|---|---|---|
| Desktop thickness | 60 mm | |
| Central knee clearance width | 900 mm | |
| Central knee clearance height | 620 mm | |
| Modesty panel slat gap | 20 mm | |
| Side pedestal width | 750 mm | |
| Curved plinth base height | 80 mm | |
| Edge band thickness | 2 mm | |
| Circular grille diameter per pedestal | 450 mm | |
| Desktop overhang front/back | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 260 kg | |
|---|---|---|
| Drawer slide rated load | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Net weight (assembled) | 210 kg | |
| Recommended user weight capacity | 150 kg | |
| Surface scratch resistance | 2H hardness | |
| Design service life | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop core and surface | Solid walnut wood frame with MDF core walnut veneer top | |
|---|---|---|
| Finish coating | Eco-friendly matte PU wood paint | |
| Front grille components | Solid beech wood vertical slats and circular lattice frames | |
| Plinth base | Solid hardwood molded curved frame with cutout feet | |
| Pedestal internal structure | 18 mm thick high-density fiberboard panels | |
| Hardware components | Zinc alloy drawer pulls, soft-close steel hinges, ball-bearing slides | |
| Edge treatment | Solid wood edge banding with rounded corner profiles | |
| Internal drawer bottoms | 5 mm thick plywood panels | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Dual pedestal storage layout | Two side pedestals each with 2 file drawers and 1 enclosed cabinet | |
|---|---|---|
| Central modesty panel | Vertical slatted panel covering knee opening for privacy | |
| Cable management grommets | Two 80 mm diameter hidden desk grommets positioned left and right of center | |
| Soft-close drawer operation | Self-closing ball-bearing slides with 350 mm extension travel | |
| Leveling foot adjustment | Adjustable feet under plinth base with 15 mm vertical adjustment | |
| Surface heat resistance | PU finish withstands 80°C contact temperature from hot beverage containers | |
| Integrated desktop layout | Smooth uninterrupted work surface with no central seam | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Suitable for 30sqm executive offices as primary work surface | |
|---|---|---|
| Corporate leadership workspace | Designed for senior management and executive daily office work | |
| High-end reception office area | Works in important visitor reception offices for host seating | |
| Matching office suite configuration | Pairs with matching high-back executive chair, wall bookcase, side tea cabinet | |
| Seated work use only | Optimized for 760 mm standard seated work height, not for standing use |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural performance | |
|---|---|---|
| EN 13722:2004 | Office furniture storage units performance requirements for pedestal components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for static load, durability and stability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to finished desk structural quality | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to internal cabinet panel materialAcceptance inspection |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to finished desk structural quality; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable to internal cabinet panel materialAcceptance inspection; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
