Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 3200 x 1200 x 760 mm | |
|---|---|---|
| desktop panel thickness | 50 mm | |
| edge banding thickness | 2 mm | |
| central knee clearance width | 1200 mm | |
| central knee clearance height | 620 mm | |
| side pedestal width | 1000 mm | |
| side pedestal depth | 650 mm | |
| bottom kickspace height | 120 mm | |
| central modesty panel height | 500 mm | |
| quatrefoil lattice cutout diameter | 320 mm | |
| central oval carved inset dimensions | 800 x 320 mm | |
| cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| desktop static load capacity | 200 kg | |
|---|---|---|
| drawer slide cycle rating | 50000 cycles | |
| cabinet hinge cycle rating | 80000 cycles | |
| desktop surface abrasion resistance | 2000 revolutions | |
| net product weight | 280 kg | |
| recommended user weight capacity | 150 kg | |
| warranty period | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| desktop core | High-density fiberboard with walnut wood veneer | |
|---|---|---|
| decorative carved inlays | Solid hardwood carved lattice and oval panels | |
| surface finish | Matte clear polyurethane lacquer | |
| pedestal frame | Engineered wood frame with solid wood edge trim | |
| drawer box construction | 15mm thick plywood with dovetail joinery | |
| drawer slides | Cold-rolled steel full-extension ball-bearing slides | |
| cabinet hinges | Soft-close cold-rolled steel concealed hinges | |
| base support rails | 40 x 40 mm solid hardwood rails | |
| modesty panel core | 25mm thick laminated engineered wood | |
| edge banding | Solid wood edge strips matching walnut finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| left pedestal storage | 2 file drawers and 1 small supply drawer with soft-close action | |
|---|---|---|
| right pedestal storage | 1 file drawer, 1 CPU storage compartment and 1 supply drawer | |
| cable management | 2 desktop cable grommets routed to under-desk cable tray | |
| under-desk cable tray load capacity | 10 kg | |
| drawer lock system | Centralized 3-drawer lock on left pedestal for secure storage | |
| base design | Open framed kickspace allowing full legroom and easy floor cleaning | |
| modesty panel function | Solid front panel blocking view of seated user's legs from front | |
| decorative ventilation | Quatrefoil lattice grilles allow passive air flow for CPU compartment | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| primary application | Executive private office for president or general manager | |
|---|---|---|
| supporting furniture pairing | Pairs with matching leather executive chair and rear bookcase cabinet | |
| space requirement | Minimum room size 4500 x 3600 mm for adequate circulation around desk | |
| style alignment | Fits new Chinese, modern traditional, or Song-dynasty aesthetic office interiors | |
| user group | C-suite executives, senior management, and corporate leadership personnel | |
| surface use case | Supports dual monitors, desk decor, keyboard, and standard office work equipment | |
| installation type | Floor-standing fixed placement, not designed for frequent reconfiguration |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables, safety and strength requirements for commercial use | |
|---|---|---|
| EN 13722:2004 | Office furniture, storage units strength and durability requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applies to load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applies to pedestal and drawer performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to structural safety | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applies to engineered wood core panels | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade minimum requirement |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to structural safety; 2. GB/T 4897.3-2003: Particleboard for furniture use, applies to engineered wood core panels; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade minimum requirement; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
