Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 950 x 760 mm | |
|---|---|---|
| Worktop thickness | 50 mm | |
| Edge band thickness | 2 mm | |
| Central knee clearance width | 800 mm | |
| Knee clearance height | 650 mm | |
| Side pedestal width | 800 mm | |
| Side pedestal depth | 600 mm | |
| Modesty panel quilted inlay size | 1200 x 200 mm | |
| Tapered leg diameter at floor | 50 mm | |
| Leg height (floor to pedestal base) | 120 mm | |
| Desk grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop static load capacity | 150 kg | |
|---|---|---|
| Individual drawer dynamic load rating | 30 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Desk net weight | 185 kg | |
| Recommended user weight capacity | 136 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended service life | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop surface | Walnut wood veneer over E0-grade engineered wood substrate | |
|---|---|---|
| Modesty panel inlay | Quilted synthetic leather upholstery over padded core | |
| Structural frame/legs | Solid hardwood tapered legs with brushed brass metal foot caps | |
| Pedestal cabinet panels | Walnut veneer over high-density fiberboard | |
| Surface finish | Water-based low-VOC clear satin lacquer | |
| Drawer hardware | Cold-rolled steel full-extension ball-bearing slides | |
| Drawer interiors | Flocked or melamine-lined engineered wood | |
| Cable management grommets | Brushed ABS plastic with flexible brush insert | |
| Joinery hardware | Zinc-plated steel cam-lock and dowel connectors | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Dual pedestal storage | Each pedestal contains 3 soft-closing drawers for office supplies and files | |
|---|---|---|
| Locking storage function | Central locking system secures all pedestal drawers for confidential document storage | |
| File drawer compatibility | Bottom drawers accommodate letter and legal size hanging file folders | |
| Cable management | Dual desk surface grommets route power and data cords to under-desk cable tray | |
| Modesty panel function | Quilted front panel blocks view of seated user legs for office privacy | |
| Floor protection | Each leg foot has non-marking rubber pad to prevent floor scratching | |
| Drawer soft-close mechanism | Integrated soft-close dampers prevent slamming and reduce noise | |
| Work surface orientation | Symmetric design allows flexible placement against wall or free-standing in office center | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Suitable for general manager and C-suite office spaces as primary work surface | |
|---|---|---|
| Boardroom ancillary space | Functions as a secondary work surface for meeting preparation or document review | |
| High-end home office | Works in luxury residential home offices for remote executive work | |
| Government institutional office | Fits formal official office spaces requiring durable, professional wood furniture | |
| Reconfiguration flexibility | Freestanding design supports office layout changes without permanent wall attachment | |
| Recommended companion furniture | Pairs with matching wood bookcases, executive leather chairs and guest seating sets | |
| Surface load suitability | Supports multiple monitors, laptops, desk lamps and document storage without deflection |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable for office work tables safety and strength requirements | |
|---|---|---|
| EN 527-2:2016 | Applicable for office work tables dimensional and mechanical safety requirements | |
| EN 13722:2004 | Applicable for office furniture storage units mechanical strength requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable for desk products safety and performance standard | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applicable for storage units safety and durability performance | |
| ANSI/BIFMA e3-2019 | Applicable for furniture sustainability and material health criteria |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for general technical requirements of wooden office furniture | |
|---|---|---|
| GB 18584-2001 | Applicable for indoor decorating material limit of harmful substances in wood furniture | |
| GB/T 4897.3-2003 | Applicable for particleboard used in furniture structural components | |
| GB/T 1931-2009 | Applicable for moisture content determination of wood used in furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for general technical requirements of wooden office furniture; 2. GB 18584-2001: Applicable for indoor decorating material limit of harmful substances in wood furniture; 3. GB/T 4897.3-2003: Applicable for particleboard used in furniture structural components; 4. GB/T 1931-2009: Applicable for moisture content determination of wood used in furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
