Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1730 x 450 x 900 mm | |
|---|---|---|
| Metal base leg height | 150 mm | |
| Individual door width | 560 mm | |
| Door panel thickness | 18 mm | |
| Carcass side panel thickness | 15 mm | |
| Internal shelf depth | 420 mm | |
| Vertical bar pull handle length | 120 mm | |
| Top surface overhang | 20 mm | |
| Back panel thickness | 9 mm | |
| Internal storage clearance height | 680 mm | |
| Edge banding thickness | 1 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top surface uniform load capacity | 30 kg | |
|---|---|---|
| Hinge open-close cycle rating | 80000 cycles | |
| Finish abrasion resistance | 2000 cycles | |
| Product net weight | 75 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Carcass core material | 15mm MDF engineered wood | |
|---|---|---|
| Door panel construction | 18mm MDF with high-gloss white paint finish | |
| Top surface material | Black high-gloss engineered stone look laminate | |
| Door decoration inlay | Gold-finish metal or painted geometric diamond lines | |
| Pull handles | Gold brushed brass-finish zinc alloy vertical bar pulls | |
| Base frame and legs | Gold powder-coated carbon steel square tube frame | |
| Door hinges | Cold-rolled steel soft-close concealed hinges | |
| Internal shelves | 15mm MDF with matching white laminate finish | |
| Edge banding | 1mm PVC edge banding matching black and white panel finishes | |
| Back panel | 9mm hardboard with black finish | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Door access | Three full-height vertical hinged doors opening 110 degrees outward | |
|---|---|---|
| Internal storage layout | Two height-adjustable shelves per door compartment, 3 separate storage bays | |
| Soft-close mechanism | Each door fitted with soft-close hinges to prevent slamming | |
| Anti-tip safety | Two wall-mounted anti-tip connectors included to secure cabinet to wall | |
| Surface maintenance | High-gloss painted and laminate surfaces are stain-resistant and wipe-clean with mild detergent | |
| Adjustable shelf positions | 5 shelf pin height positions per bay, allowing 100mm incremental height adjustment | |
| Leveling adjustment | Small adjustable feet integrated into leg bases to compensate for uneven floors | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Dining room use | Placed against dining wall to store tableware, linens and serving pieces | |
|---|---|---|
| Entryway use | Positioned in foyer as accent storage for keys, mail and entry accessories | |
| Living room use | Used as decorative media or display storage against living room walls | |
| Luxury residential interiors | Matches modern, contemporary and glam decor schemes with gold and white finish | |
| Small to medium apartment fit | 1730mm width fits most standard apartment wall spaces without overwhelming rooms | |
| Commercial space use | Suitable for boutique hotel lobbies, luxury retail back-of-house storage |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and structural performance requirements for domestic and kitchen storage cabinets | |
|---|---|---|
| EN 16121:2013 | Storage furniture for non-domestic use - safety, strength and durability requirements | |
| EN 12521:2015 | Furniture - strength, durability and safety requirements for domestic tables |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and finish quality checks | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture | |
| GB/T 4893.8-2013 | Test for surface resistance to abrasion for furniture finishes |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and finish quality checks; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture; 3. GB/T 4893.8-2013: Test for surface resistance to abrasion for furniture finishes; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
