PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

数据来源：工厂资料结构化字段，最终以实测值为准

产品外部尺寸（宽 × 深 × 高）	610 × 650 × 1010 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

数据来源：产品性能数据，采购前请核对具体测试口径

Net weight	13.5 kg
Recommended user weight capacity	160 kg
Suggested daily occupancy	8 hours
Frame static verification load	640 kg
Seat impact durability	100,000 cycles
Backrest backward load	136 kg
Arm downward load	90 kg per arm
Tip resistance rearward	12 degrees
Glide floor load	25 kg per glide
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%

PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

数据来源：以工厂材质清单与验货报告为准

Seat upholstery	Black smooth upholstery over padded cushion, likely leather-look PU or genuine leather option
Back upholstery	Black padded upholstered panel with subtly rounded top corners and clean perimeter stitching
Seat cushion core	Molded polyurethane foam at 80 mm thickness, recommended density 45 kg/m3
Back cushion core	Shaped polyurethane foam at 50 mm effective thickness, recommended density 35 kg/m3
Internal seat support	12 mm molded hardwood-composite board or steel-reinforced plywood seat carrier
Internal back carrier	8 mm molded board or bent plywood panel attached to the steel frame
Frame	One-piece polished chrome-plated mild-steel cantilever tube, 25 mm diameter and 1.8 mm wall thickness
Armrests	Continuous chrome tubular supports with padded or wrapped horizontal black arm surfaces
Floor glides	Four non-marking polymer or nylon glide inserts at the sled rail ends
Surface finish	Bright polished chrome plating with multi-layer nickel undercoat recommended
Seam construction	Single perimeter upholstery seam with 7 stitches per 50 mm recommended
Frame fasteners	M8 steel mounting bolts or riveted hinges between back/seat carrier and frame

PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

数据来源：功能配置参数，以供应商正式规格为准

Fixed cantilever suspension	Continuous sled frame flexes slightly under load without tilt mechanism or gas lift
Fixed arm support	Integrated tubular armrests provide forearm support at 680 mm floor height and do not adjust
Static upright seating	Tall padded back supports upright posture for meetings, with no recline lock or headrest
Floor protection	Four polymer end glides allow short repositioning while reducing floor scratching
Stacking capability	Non-stacking single chair, as the fixed back and arm frame would obstruct nesting
Movement	Non-swivel fixed-position chair requiring the occupant to reposition the whole chair
Assembly method	Frame-mounted back and seat likely ship partly assembled; glides insert into four rail ends
Maintenance access	Upholstery can be wiped clean; frame fasteners should be checked after the first 30 days of commercial use
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Height Adjustment Stroke	100 mm continuous travel
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

数据来源：外贸报价与装柜测算参考

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

数据来源：依据产品结构与品类整理的推荐应用场景

Conference rooms	Use around 750 mm high meeting tables where fixed quiet seating and a uniform executive look are required
Executive reception	Place in pairs in reception or visitor areas with desks, sofas, or low tables
Training discussion rooms	Suitable for short-to-medium-duration sessions with frequent user changes
Manager office visitor side	Position one or two chairs in front of an executive desk for guests
Commercial project furnishing	Suitable for bulk procurement where identical black frames and replacement consistency are needed
Hard-floor spaces	Use on tile, wood, or sealed floors with the four non-marking glides
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 16139 applicability	Use for strength, durability, and safety of non-domestic contract seating
EN 1022 applicability	Use for stability testing of the fixed cantilever chair on a level test platform
EN 12521 applicability	Use as the European furniture safety reference for non-domestic seating if specified

STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

ANSI/BIFMA X5.1 durability applicability	Use 100,000-cycle seat impact and cyclic back-load testing

STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 10357.2 applicability	Use for chair seat and back mechanical stability acceptance testing
GB/T 10357.3 applicability	Use for chair strength and durability testing of seat, back, and arm loads
GB 18584 applicability	Use for indoor-furniture hazardous-substance limits on wooden and upholstered components

招标文件标准化描述文本

本产品须满足以下技术参数要求：
1. GB/T 10357.2 applicability：Use for chair seat and back mechanical stability acceptance testing；
2. GB/T 10357.3 applicability：Use for chair strength and durability testing of seat, back, and arm loads；
3. GB 18584 applicability：Use for indoor-furniture hazardous-substance limits on wooden and upholstered components；
最终交付参数、检测报告和验收标准以双方采购合同为准。

GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告，可选择公制或英制单位。

PDF · CF-CH-BLK-SLED-01

完整参数 Excel

导出全部商品信息与参数模块，文件内容统一使用英文。

XLSX · CF-CH-BLK-SLED-01

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段，可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · CF-CH-BLK-SLED-01打开导出工具

页面快速操作

发布采购询价

产品描述

The Black Padded Cantilever Conference Chair combines a restrained executive appearance with a streamlined sled-base structure. Its black upholstered seat and tall back create a consistent visual profile, while subtly rounded top corners and clean perimeter stitching give the backrest a refined finish. A polished chrome-plated cantilever frame defines the side silhouette, and continuous tubular armrests reinforce the chair’s minimalist, commercial character. The fixed layout presents a neat, uniform seating solution for settings where coordinated furniture is preferred. Each chair measures 610 mm in width, 650 mm in depth, and 1010 mm in overall height, with a 540 mm clear width between the armrests. The finished seat cushion is 90 mm thick and the backrest padding is 70 mm thick, including a 240 mm high lumbar support zone. Construction centers on a one-piece polished chrome-plated mild-steel cantilever tube with a 25 mm diameter and 1.8 mm wall thickness. The seat uses molded polyurethane foam over a molded hardwood-composite board or steel-reinforced plywood carrier, while the shaped back foam is supported by a molded board or bent plywood panel attached to the steel frame. The black smooth upholstery is presented in a leather-look material, with a genuine leather option available. Armrests follow the chrome frame and include padded or wrapped black horizontal surfaces. Four non-marking polymer or nylon glides fit the sled rail ends. Functionally, the chair is designed for static, upright meeting use rather than active task seating. The cantilever frame flexes slightly under load, but there is no tilt mechanism, gas lift, swivel action, recline lock, headrest, or armrest adjustment. The fixed arm supports sit 680 mm above the floor, and the glides allow limited repositioning while helping to reduce scratching on hard surfaces. The chair is non-stacking and non-nesting. It is suited to conference rooms with 750 mm high meeting tables, executive reception areas, training discussion rooms, and guest seating across manager desks. Its consistent black-and-chrome appearance also makes it appropriate for commercial projects requiring identical seating across multiple rooms or phases. On hard tile, wood, or sealed floors, the supplied glides should be fitted correctly. Procurement teams should note the unbranded model CF-CH-BLK-SLED-01, 13.5 kg net weight, 160 kg recommended user weight capacity, and suggested eight-hour daily occupancy. Delivery is referenced as one set across two cartons, with packaged weight of 23 kg and an indicative assembly time of 40 minutes per set. Buyers should confirm upholstery choice, armrest surface finish, assembly requirements, replacement availability, and floor-protection expectations before placing project orders.

Black Padded Cantilever Conference Chair with Chrome Sled Frame and Fixed Armrests Specifications
