Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1400 × 800 × 750 mm | |
|---|---|---|
| Tabletop thickness | 45 mm | |
| Leg cross-section | 60 x 60 mm square | |
| Leg wall thickness (solid wood) | 60 mm | |
| Apron height | 100 mm | |
| Apron thickness | 25 mm | |
| Under-table knee clearance height | 605 mm | |
| Tabletop edge radius | 3 mm | |
| Leg floor contact pad diameter | 30 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed static tabletop load | 100 kg | |
|---|---|---|
| Single leg static vertical load | 40 kg | |
| Net product weight | 32 kg | |
| Surface finish abrasion resistance | 1000 cycles | |
| Wood moisture content | 12% | |
| Wobble deflection under full load | 2 mm | |
| Finish coating thickness | 0.15 mm | |
| Connector size (corner bolt) | M8 x 60 mm | |
| Seating capacity per long side | 2 people | |
| Top Static Load Reference | 150 kg uniformly distributed |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop | Solid rubberwood with natural clear matte finish | |
|---|---|---|
| Support legs | Solid square hardwood, matching natural wood tone | |
| Connecting apron | Solid hardwood, mortise-and-tenon or bolted joint to legs | |
| Surface finish | Water-based clear matte lacquer, low-VOC formulation | |
| Corner hardware | Zinc-plated steel bolts and barrel nuts for knockdown assembly | |
| Floor contact pads | Non-marking TPE rubber pads adhered to leg bases | |
| Wood surface treatment | Sanded to 240-grit smoothness before finish application | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Table structure | Fixed non-extendable rectangular top, no leaf storage | |
|---|---|---|
| Assembly type | Knockdown assembly, legs attach to apron with included hardware | |
| Seating access | Unobstructed access on all four sides for 4 diners | |
| Floor protection | Non-marking rubber feet prevent hardwood floor scratching | |
| Surface maintenance | Non-porous finish allows wipe-clean with damp cloth | |
| Load distribution | Apron frame transfers tabletop load evenly to four corner legs | |
| Stability design | Four corner leg placement provides 1400x800mm support base | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Packaging volume (CBM) | 0.261 | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room | Fits 4-person household daily meals with compact rectangular footprint | |
|---|---|---|
| Open-plan kitchen diner | Light natural wood tone complements neutral, Nordic or Japandi interior schemes | |
| Small apartment breakfast nook | 1400mm length fits compact spaces without occupying excess floor area | |
| Casual meeting space in small office | Works for team break rooms or informal small group meeting areas | |
| Rental property furnishing | Durable solid wood construction withstands frequent use in furnished rentals | |
| Cafe small dining seating | Suitable for independent cafes serving 2-person and 4-person dining parties |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture strength, durability and safety requirements for domestic dining tables, applies to performance validation | |
|---|---|---|
| EN 71-3:2019 | Migration of certain elements safety standard, applies if used in households with children | |
| EN 15187:2007 | Assessment of surface resistance to cold liquids for furniture, applies to finish spill resistance |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to dimensional and structural acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for wood furniture, applies to material safety | |
| GB/T 4893.8-2013 | Furniture surface test for abrasion resistance, applies to finish durability acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to dimensional and structural acceptance; 2. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wood furniture, applies to material safety; 3. GB/T 4893.8-2013: Furniture surface test for abrasion resistance, applies to finish durability acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
