Automatic mm / inch conversion · Core engineering specifications
| Overall unit dimensions | 4800 x 400 x 2200 mm | |
|---|---|---|
| Central open recess width | 2400 mm | |
| Central open shelf height above lower cabinet | 1020 mm | |
| Side glass-front display section width | 600 mm per side section | |
| Adjustable shelf vertical spacing | 350 mm | |
| Lower closed cabinet compartment height | 780 mm | |
| Solid wood door panel thickness | 25 mm | |
| Tempered glass door thickness | 5 mm | |
| Shelf board thickness | 25 mm | |
| Decorative crown molding projection | 30 mm | |
| Base plinth height | 80 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Per adjustable shelf static load capacity | 40 kg | |
|---|---|---|
| Lower cabinet drawer/shelf static load | 50 kg | |
| Hinge open/close cycle durability | 80000 cycles | |
| Door hinge opening angle | 110 degrees | |
| Fully loaded unit total weight | 380 kg | |
| Recommended maximum uniform wall load | 600 kg | |
| Finish surface abrasion resistance | 2000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Carcass core material | High-density fiberboard with density ≥730kg/m³ | |
|---|---|---|
| Exterior finish | Red wood veneer with high-gloss polyurethane paint | |
| Upper side display doors | 5mm tempered safety glass | |
| Lower cabinet doors | Raised-panel solid wood veneer with framed construction | |
| Door hardware | Zinc alloy antique brass pull handles, soft-close hydraulic hinges | |
| Back panel material | 9mm solid wood veneer slat panel | |
| Shelf boards | 25mm thick veneered high-density fiberboard with PUR edge banding | |
| Adjustable shelf supports | Metal pin shelf supports with 32mm hole spacing | |
| Base and crown trim | Solid wood veneer molded trim matching main finish | |
| Edge banding | 1mm thick PUR hot-melt edge band with ≤0.1mm glue seam | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Side section storage layout | Upper 4-shelf glass-enclosed display, lower 2-door closed storage | |
|---|---|---|
| Central section layout | Full-width open display recess above 3 pairs of double-door closed storage | |
| Shelf adjustability | 3 adjustable shelf positions per glass compartment, 50mm increment adjustment | |
| Door operation | Soft-close hydraulic hinges with damping, closing noise ≤30dB | |
| Anti-tip safety | 2 wall-mounted anti-tip brackets per section, total 6 brackets | |
| Leveling adjustment | Adjustable leveling feet at base with 15mm height adjustment | |
| Storage configuration | 12 total closed storage compartments, 8 open display shelves | |
| Optional lock compatibility | Pre-drilled holes for optional cabinet door locks for secure document storage | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Executive office background wall | Installed behind executive desk for document storage and decorative display | |
|---|---|---|
| Boardroom perimeter storage | Used for meeting material storage and corporate award/decor display in formal boardrooms | |
| High-end reception area display | Placed in reception areas to display company credentials, books and decorative items | |
| Private study luxury storage | Suitable for high-end residential private studies requiring traditional formal wood furniture styling | |
| Target user | Executive leadership, senior management, premium corporate office procurement | |
| Recommended matching furniture | Paired with matching traditional red wood executive desk, leather executive chair and visitor seating | |
| Storage suitability | Holds standard A4 documents, hardcover books, decorative ornaments and office supplies |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops, safety requirements applicable for cabinet stability | |
|---|---|---|
| EN 12521:2015 | Furniture - Strength, durability and safety for non-domestic storage furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and finish quality acceptance | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for core board performance verification | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, required for indoor office use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and finish quality acceptance; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable for core board performance verification; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, required for indoor office use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
