Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3600 x 450 x 2200 mm | |
|---|---|---|
| Central display niche dimensions | 720 x 400 x 850 mm | |
| Per-side open shelf tier height | 320 mm | |
| Lower cabinet door height | 820 mm | |
| Open shelf depth | 320 mm | |
| Enclosed cabinet door panel thickness | 25 mm | |
| Adjustable shelf thickness | 25 mm | |
| Carcass side panel thickness | 25 mm | |
| Top decorative eave trim overhang | 50 mm | |
| Base plinth height | 120 mm | |
| Metal vertical pull handle length | 120 mm | |
| Outer full-height door section width | 720 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Unit net weight range | 380 kg | |
|---|---|---|
| Per shelf static load capacity | 30 kg | |
| Lower cabinet interior storage volume per door | 0.24 m³ | |
| Maximum book storage capacity | 450 standard hardcover volumes | |
| Wood moisture content | 10% | |
| Hinge opening angle | 110 degrees | |
| Hinge cycle durability | 80000 open/close cycles | |
| Door sag maximum allowance | 3.0 mm | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Carcass framework | Solid hardwood or 0.8mm natural wood veneer over E0 MDF | |
|---|---|---|
| Surface finish | Environmentally friendly water-based wood lacquer, semi-gloss red-brown tone | |
| Shelf panels | 25mm thick solid wood/wood-composite core with matching veneer | |
| Door panels | Raised-and-recessed solid wood framed panels with decorative edge molding | |
| Hardware pulls | Polished chrome-plated zinc alloy vertical bar pulls, paired per double door | |
| Back panel | 9mm thick plywood with wood veneer finish | |
| Edge banding | 1.0mm thick solid wood edge banding, color-matched to main finish | |
| Top decorative trim | Solid wood carved upturned eave trim with integrated carved detailing | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | 10 lower enclosed double-door compartments, 12 upper open shelves, 1 central display niche | |
|---|---|---|
| Central top drawer | 1 shallow recessed panel drawer above display niche for small item storage | |
| Shelf adjustability | 3 position adjustable shelf pins in open shelf sections for variable item heights | |
| Door operation | Double doors open outwards via concealed hinges, with optional key locks for secure storage | |
| Anti-tip safety | 2 wall-mounted anti-tip connectors included to secure unit to wall surface | |
| Display function | Central open niche designed for decorative art, trophies or branded display items | |
| Assembly requirement | Knock-down 4-section assembly with cam-lock connectors for on-site installation | |
| Surface durability | Lacquer finish resists common office stains, scratches and fading with regular use | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Executive office placement | Positioned behind executive desk as background storage for chairman or director offices | |
|---|---|---|
| VIP reception room use | Placed against feature wall for book storage and decorative display in high-end reception areas | |
| Storage function for offices | Stores documents, reference books, awards, collectibles and office supplies in mixed open/enclosed layout | |
| Matching furniture set | Pairs with matching red-brown solid wood executive desk, conference table and guest seating for unified office design | |
| Commercial office project suitability | Suitable for government, corporate headquarters and private enterprise executive floor fit-out projects | |
| Installation requirement | Requires flat load-bearing wall installation with anti-tip fixing for safety in high-traffic office environments |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and finish acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture | |
| GB/T 1931-2009 | Method for determination of moisture content of wood, applicable for raw material inspection |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and finish acceptance; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture; 3. GB/T 1931-2009: Method for determination of moisture content of wood, applicable for raw material inspection; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
