Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 3600 x 450 x 2200 mm | |
|---|---|---|
| Central display niche dimensions | 1200 x 400 x 900 mm | |
| Lower cabinet door height | 800 mm | |
| Open shelf compartment width (side sections) | 400 mm | |
| Open shelf vertical clearance | 320 mm | |
| Outer solid panel door width | 500 mm | |
| Decorative top trim height | 120 mm | |
| Plinth base height | 100 mm | |
| Shelf thickness | 25 mm | |
| Back panel thickness | 16 mm | |
| Side/door panel thickness | 18 mm | |
| Solid wood edge banding thickness | 6 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm |
Net weight / load capacity / users / durability
| Unit net weight | 380 kg | |
|---|---|---|
| Per open shelf static load capacity | 40 kg | |
| Recommended maximum load (whole unit) | 600 kg | |
| Door hinge cycle rating | 80000 cycles | |
| Adjustable shelf count | 12 | |
| Paint finish hardness | 2H | |
| Wood moisture content | 12% | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Cabinet carcass | Solid wood core with natural wood veneer, E0 grade substrate | |
|---|---|---|
| Door panels | Raised solid wood panels, red-brown polyurethane painted finish | |
| Shelf boards | 25mm thick solid wood veneered board, sealed all edges | |
| Back panel | 16mm thick engineered wood with matching wood veneer | |
| Top trim and plinth | Carved solid wood, matching red-brown finish | |
| Door pulls | Brushed zinc alloy drop handles, symmetrical mounting | |
| Locks | Keyed cam locks on outer lower cabinet doors | |
| Hinges and slides | DTC-grade cold-rolled steel soft-close hardware | |
| Finish coating | Water-based PU paint, acid and heat resistant | |
| Edge banding | 6mm solid wood edge banding on all exposed panel edges | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Locked storage | Keyed locks on 2 outer lower cabinet doors, secures confidential documents | |
|---|---|---|
| Adjustable shelving | 12 adjustable shelves on metal support pins, 5 height positions per compartment | |
| Central display niche | Open recessed center compartment for decorative art or awards, no door | |
| Closed concealed storage | 16 lower cabinet doors, fully enclosed for hidden supply and file storage | |
| Open book storage | 8 upper open shelf compartments, holds upright books, binders and reference materials | |
| Door operation | Hinged doors open 110 degrees, soft-close action prevents slamming | |
| Wall anchoring provision | 2 anti-tip connector brackets at rear top edge for wall fixation | |
| Configuration compatibility | Pairs with matching executive desk sets for full executive office layouts | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Installed as background wall storage behind executive desk for documents and display | |
|---|---|---|
| Manager/director office | Provides secure file storage and display space for senior management offices | |
| Boardroom ancillary storage | Placed along boardroom wall for reference documents, awards and meeting supplies | |
| High-end reception/meeting lounge | Used to display corporate awards, artifacts and branded collateral | |
| Configuration recommendation | Paired with matching 3600 mm wide executive desk and side cabinet for cohesive office set | |
| Style compatibility | Suits traditional, new-Chinese and classic mahogany-toned commercial office interior schemes | |
| User group suitability | Designed for C-suite executives, senior managers, and organizational leadership office environments |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office furniture – Storage furniture, Part 2: Safety requirements, applicable for stability testing | |
|---|---|---|
| EN 14749:2016 | Domestic and kitchen storage units and worktops – Safety requirements, applicable for structural strength | |
| EN 12720:2009+A1:2013 | Furniture – Assessment of surface resistance to cold liquids, applicable for paint finish performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage Furniture – Tests for safety, durability, and structural integrity, applicable for commercial office acceptance | |
|---|---|---|
| ANSI/BIFMA M7.1-2020 | Standard test method for determining VOC emissions from office furniture systems | |
| ANSI/BIFMA X5.1-2017 | General-purpose office chairs (non-applicable to this cabinet category, excluded) |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials – limit of harmful substances for wooden furniture, formaldehyde emission ≤0.05mg/m³ | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for engineered wood substrate performance requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural acceptance; 2. GB 18584-2001: Indoor decorating and refurbishing materials – limit of harmful substances for wooden furniture, formaldehyde emission ≤0.05mg/m³; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable for engineered wood substrate performance requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
