| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Carcass Panel Thickness | 25 mm | |
|---|---|---|
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Product net weight | 18 kg | |
|---|---|---|
| Top surface static load | 30 kg | |
| Top drawer distributed load | 10 kg | |
| Middle drawer distributed load | 10 kg | |
| Bottom file drawer distributed load | 15 kg | |
| Drawer slide durability | 20,000 open/close cycles | |
| Caster dynamic load | 40 kg total across four casters | |
| Single-caster load capacity | 15 kg | |
| Anti-tip interlock | One drawer opens at a time | |
| Tip restraint strength | 220 N horizontal restraint force |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Top panel | 25 mm wood-based particleboard core with light oak-grain melamine face and sealed underside | |
|---|---|---|
| Drawer fronts | 18 mm wood-based panels with light oak-grain melamine face and straight PVC edge banding | |
| Side and carcass panels | 18 mm white melamine-faced wood-based panels with matching white edge sealing | |
| Back panel | 9 mm hardboard or melamine-faced hardboard recessed into a rabbeted rear frame | |
| Bottom plinth | 18 mm white melamine-faced wood-based base rail connected to four caster mounting plates | |
| Drawer boxes | 12 mm white melamine-faced wood-based sides with a 12 mm base and reinforced rear corner blocks | |
| Edge banding | 2 mm PVC impact-resistant edge banding on exposed top and front edges, 0.6 mm PVC on concealed edges | |
| Drawer slides | Side-mounted galvanized steel full-extension ball-bearing slides with plastic anti-slide stops |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Drawer storage | Three vertically stacked drawers provide 30 l total enclosed storage for stationery and files | |
|---|---|---|
| File organization | Bottom drawer accepts A4 or foolscap suspension-file rails across its 330 mm clear width | |
| Drawer extension | Each drawer opens on full-extension slides with 420 mm travel and positive stop at full extension |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Under-desk office storage | Place beside a 760 mm workdesk for seated access to A4 documents and personal items; 620 mm height fits below standard work surfaces | |
|---|---|---|
| Open-plan workstation | Use in hot-desks or shared workpoints where the combination lock secures three drawers without issuing keys to every user |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.9 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
