Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall cabinet size | 411 x 549 x 711 mm | |
|---|---|---|
| Top work surface | 411 x 549 mm | |
| Front opening width | 311 mm | |
| Upper stationery drawer interior | 311 x 387 x 64 mm | |
| Middle stationery drawer interior | 311 x 387 x 64 mm | |
| Lower hanging-file drawer interior | 311 x 387 x 245 mm | |
| Drawer front upper height | 178 mm | |
| Drawer front middle height | 178 mm | |
| Drawer front lower height | 274 mm | |
| Caster diameter | 51 mm | |
| Caster tread width | 35 mm | |
| Base plinth height | 51 mm | |
| Ground clearance under body | 13 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Unit net weight | 32.7 kg | |
|---|---|---|
| Total static storage load | 68 kg | |
| Load per drawer | 25 kg | |
| Top surface static load | 35 kg | |
| File drawer load | 25 kg | |
| Upper and middle drawer load | 25 kg each | |
| Caster rated capacity per set | 90 kg | |
| Rolling durability | 20,000 cycles | |
| Drawer slide durability | 50,000 open-close cycles | |
| Recommended seated users | 1 person per pedestal |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Drawer fronts | 18 mm engineered-wood panels with walnut grain melamine or laminate face | |
|---|---|---|
| Top panel | 25 mm engineered-wood panel with walnut wood-grain laminate and eased edge | |
| Side panels | 18 mm gray painted or melamine-faced composite panels with smooth matte surface | |
| Back panel | 9 mm engineered-wood or hardboard back set into a rabbeted rear frame | |
| Drawer boxes | 12 mm laminated engineered-wood drawer sides with formed recessed pulls | |
| Base plinth | 0.8 mm powder-coated gray steel rail connecting the lower corners | |
| Drawer slides | Full-extension side-mounted ball-bearing metal slides with retained rail stops | |
| Caster wheels | Black nylon or polyurethane twin-wheel swivel casters with steel mounting stems |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Drawer operation | Two upper stationery drawers and one lower file drawer open on full-extension slides for back-area access; loaded drawer limit is 25 kg. | |
|---|---|---|
| Locking system | The upper-mounted combination and key lock controls a central cam that locks all three drawers and provides key override entry. | |
| File organization | The lower drawer accepts a removable hanging-file bar for A4, letter, or legal folders with side-to-side rail adjustment. |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Administrative filing area | Use in clusters for HR, accounting, or reception records where mobile filing and lockable privacy are required. |
|---|
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.9 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
