| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall cabinet size | 800 x 400 x 800 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Maximum total static load | 60 kg | |
|---|---|---|
| Top surface load | 30 kg | |
| Fixed open-shelf load | 15 kg per shelf | |
| Drawer load | 10 kg | |
| Lower enclosed compartment load | 20 kg | |
| Storage volume | 0.18 m3 | |
| Open shelf count | 2 shelves | |
| Lockable storage sections | 2 sections | |
| Leveling adjustment | 10 mm travel per foot | |
| Shelf Distributed Load | 30 kg/shelf |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Top panel | 25 mm light oak-grain melamine-faced wood-based panel with matching edge banding | |
|---|---|---|
| Drawer and door fronts | 18 mm light oak-grain melamine-faced panels with flush recessed gaps | |
| Carcass and interior | 18 mm white melamine-faced panels forming sides, base, shelf and internal dividers | |
| Back enclosure | 9 mm light-gray or white melamine-faced hardboard/MDF back panel | |
| Lock | Black metal-face three-digit combination lock with silver actuator | |
| Support feet | Four white cylindrical plastic adjustable leveling feet with threaded inserts |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Combination locking | Three-digit combination lock secures the upper drawer and lower left storage door for personal or departmental use | |
|---|---|---|
| Drawer storage | One shallow 160 mm-front drawer provides separated storage for stationery, tablets, wallets and documents | |
| Enclosed lower cabinet | One 560 mm-high hinged door conceals a full-depth storage compartment suitable for files or personal items | |
| Open shelving | Two fixed right-hand cubbies provide 280 mm-high immediate-access storage for books, boxes and frequently used materials |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Packed carton count | 1 flat-pack carton | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.9 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
