| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall cabinet size | 420 x 520 x 620 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total static load capacity | 60 kg distributed across the cabinet and drawers | |
|---|---|---|
| Top surface distributed load | 40 kg | |
| Top and middle drawer load | 10 kg per drawer | |
| Bottom file drawer load | 25 kg evenly distributed | |
| Drawer slide durability | 50,000 complete open-close cycles per drawer | |
| Caster dynamic load | 15 kg per caster on level hard flooring | |
| Caster durability | 20,000 swivel-and-roll cycles without loss of fixing torque | |
| Lock mechanism durability | 10,000 locking cycles without code failure | |
| Loaded cabinet stability | Remains stable on a 2 degree level floor with all drawers closed | |
| Anti-tip safety | One drawer opens at a time when loaded to rated capacity and fitted with the supplied wall anchor |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Top panel | 25 mm melamine-faced composite board with walnut woodgrain decor and sealed exposed edges | |
|---|---|---|
| Drawer fronts | 18 mm melamine-faced composite board with horizontal walnut grain and flush 2 mm gaps | |
| Side panels | 18 mm graphite-grey melamine-faced composite board with a smooth matte finish | |
| Back panel | 9 mm composite backing panel recessed into the carcass perimeter | |
| Drawer boxes | 15 mm melamine-lined composite drawer boxes with metal bottom retainers | |
| Edge banding | 2 mm black PVC edge banding on exposed front, top, and base edges | |
| Base plinth | 20 x 30 mm black powder-coated steel rail connecting the lower corners | |
| Drawer slides | Full-extension side-mounted ball-bearing steel slides with black zinc finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Centralized drawer locking | Three-digit combination lock secures all three drawers through a steel linkage and includes a manual lock indicator | |
|---|---|---|
| Full-extension drawers | Each drawer travels 430 mm on side-mounted ball-bearing slides for complete rear access | |
| Three-level storage layout | Two 120 mm utility drawers and one 220 mm file drawer provide separate stationery and document storage |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Manager or private office | used beside an executive desk to secure confidential paperwork with the three-digit lock and maintain a mobile work zone. | |
|---|---|---|
| Hot-desk and coworking space | rolled between workpoints by staff needing temporary personal storage without occupying a fixed room. |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.9 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
