Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 300 x 400 x 1200 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 32 kg | |
|---|---|---|
| Top surface static load | 25 kg | |
| Shelf static load | 15 kg per shelf | |
| Total cabinet static load | 75 kg | |
| Storage volume | 0.126 m3 | |
| Internal shelf count | 4 shelves | |
| Recommended wall-anchor load | 500 N pull resistance | |
| Warranty | 5 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Top panel | 25 mm melamine-faced engineered wood with light oak-woodgrain finish and matching edge banding | |
|---|---|---|
| Door panel | 18 mm light oak-woodgrain melamine-faced engineered wood with a flat slab profile | |
| Side and carcass panels | 18 mm light gray melamine-faced engineered wood with square edges | |
| Back panel | 5 mm hardboard or melamine-faced thin back panel set into a rebated carcass | |
| Edge banding | PVC or ABS edge banding in matching oak and light gray finishes, 2 mm thick | |
| Shelf support hardware | Nickel-plated steel shelf pins, 5 mm shank, four pins per shelf | |
| Leveling feet | Rigid polymer round adjustable feet with 20 mm exposed height | |
| Door hinge system | Concealed steel cup hinges with 105 degree opening angle and side adjustment screws |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Door and storage access | Full-height hinged slab door opens 105 degrees on concealed cup hinges and provides access to five shelf compartments; shelves adjust on 32 mm vertical pitch for binders and office materials | |
|---|---|---|
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office and institutional storage | Suitable for individual workstations, administrative rooms, clinics, and classrooms where binders, samples, or personal items require a 300 mm-wide vertical storage footprint | |
|---|---|---|
| Ancillary room placement | Place against a wall in pantries, copy rooms, reception back areas, or limited-width corridors; anchor to the wall before loading the top shelf to reduce tip-over risk |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.9 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
