| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Carcass Panel Thickness | 25 mm | |
|---|---|---|
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 32 kg | |
|---|---|---|
| Top surface distributed load | 40 kg | |
| Drawer load capacity | 15 kg evenly distributed | |
| Bottom compartment floor load | 20 kg evenly distributed | |
| Combination lock code capacity | 3 user digits | |
| Color options | 2 visible finishes: walnut-grain and light grey | |
| Suggested warranty | 3 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Top panel | Walnut-grain melamine-faced board with a straight edge band and slight overhang | |
|---|---|---|
| Drawer front | Walnut-grain melamine-faced panel with a horizontal recessed reveal | |
| Lower door | Walnut-grain melamine-faced panel hinged within the left carcass | |
| Carcass and shelves | Light grey melamine-faced engineered board with matching edge banding | |
| Central divider | 18 mm vertical melamine board separating locked storage from open shelving | |
| Fixed shelf | 18 mm light grey melamine shelf secured between side panels | |
| Drawer lock | Black metal-faced three-dial combination lock with silver release or key component | |
| Drawer slides and hinges | Steel side-mounted drawer runners and concealed cabinet hinges |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Secured storage | Three-dial combination lock locks the upper drawer and coordinates with the left storage zone for confidential office materials | |
|---|---|---|
| Open retrieval storage | Right bay provides two front-access open compartments separated by a fixed shelf for books, boxes and frequently used items | |
| Floor protection and leveling | Four raised cylindrical feet lift the cabinet 30 mm and provide limited leveling on office floors |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office side storage | Place beside a workstation for locked personal storage in the left module and quick-access books or binders in the open right bay | |
|---|---|---|
| Administrative or reception workspace | Use under counters or alongside desks for forms, stationery, box files and confidential documents secured by the combination lock |
EU Market Access Requirements* EN Standards
| Office furniture safety recommendation | EN 14073for safety requirements of office storage furniture | |
|---|---|---|
| Office storage durability recommendation | EN 14073for stability and strength test methods | |
| Formaldehyde recommendation | EN 13986 wood-based panels for building applications, with E1 formaldehyde class specified in procurement |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
| Formaldehyde emission recommendation | GB/T 39600, E1 limit for artificial-board components used in indoor office furniture | |
|---|---|---|
| Wooden furniture quality recommendation | GB/T 3324 general technical requirements for wooden furniture | |
| Office cabinet safety recommendation | GB/T 10357.5 mechanical test for furniture strength and durability |
This product must meet the following technical requirements: 1. Formaldehyde emission recommendation: GB/T 39600, E1 limit for artificial-board components used in indoor office furniture; 2. Wooden furniture quality recommendation: GB/T 3324 general technical requirements for wooden furniture; 3. Office cabinet safety recommendation: GB/T 10357.5 mechanical test for furniture strength and durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
