Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall cabinet size | 390 x 390 x 1800 mm | |
|---|---|---|
| interior storage size | 354 x 358 x 1720 mm | |
| Door front size | 354 x 1690 mm | |
| Door thickness | 18 mm | |
| Carcass side panel thickness | 18 mm | |
| Back panel thickness | 5 mm | |
| Recessed pull opening | 310 x 18 mm | |
| Adjustable shelf count | 4 shelves | |
| Shelf panel size | 350 x 350 mm | |
| Shelf thickness | 16 mm | |
| Shelf center spacing | 300 mm | |
| Leveling foot diameter | 25 mm | |
| Leveling foot exposed height | 20 mm | |
| Top surface usable area | 390 x 390 mm | |
| Toe clearance under cabinet | 20 mm | |
| Carcass Panel Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 18 kg | |
|---|---|---|
| Top surface load | 15 kg | |
| Per-shelf distributed load | 9 kg | |
| Total cabinet storage load | 45 kg | |
| Recommended loaded center of gravity | Below 900 mm | |
| Door hinge static rating | 8 kg per hinge | |
| Hinge operating cycles | 30,000 open-close cycles | |
| Slide or drawer cycles | 0 cycles | |
| Anti-tip restraint load | 50 kg pull resistance | |
| Shelf Distributed Load | 30 kg/shelf |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass panels | 18 mm engineered wood board with white smooth surface and sealed edges | |
|---|---|---|
| Door panel | 18 mm white board panel with flush uninterrupted face and matching edge treatment | |
| Back panel | 5 mm hardboard or composite backing fitted into rear grooves | |
| Shelves | 16 mm white board panels supported by metal or plastic shelf pegs | |
| Surface finish | White thermofused melamine or foil-finished surface for wipe-clean use | |
| Edge banding | 1 mm PVC or ABS edge banding on exposed door and carcass edges | |
| Recessed pull | Dark grey plastic or painted metal inset grip in the upper door reveal | |
| Leveling feet | Four cylindrical plastic feet with concealed metal threaded stems |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Door access | Single tall flush door opens by the dark upper recessed pull and provides access to four shelf levels | |
|---|---|---|
| Shelf adjustment | Four shelves use removable support pegs to change vertical positions along pre-drilled interior rows | |
| Leveling | Four threaded cylindrical feet compensate for uneven floors and lift the base 20 mm above the floor |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Small-space vertical storage | Use in bathrooms, laundry corners, entry niches, kitchens, or narrow office gaps where 390 mm floor space is available | |
|---|---|---|
| General household or office storage | Store cleaning supplies, documents, folded textiles, pantry goods, or display objects with wall anchoring and lower-heavy loading |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
