Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall cabinet size | 400 x 420 x 750 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 24 kg | |
|---|---|---|
| Top surface distributed load | 30 kg | |
| Drawer load capacity | 10 kg | |
| Lower compartment shelf capacity | 15 kg per level | |
| Whole-cabinet stability load | 60 kg static vertical load | |
| Recommended loaded moving weight | 24 kg empty; 55 kg loaded | |
| User capacity | 1 user | |
| Warranty reference | 3 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Top panel | 25 mm wood-based board with white melamine surface and sealed edge | |
|---|---|---|
| Front surfaces | 18 mm wood-based board with light oak-look melamine veneer | |
| Side and back panels | White melamine-faced wood-based board with square edge finish | |
| Internal shelf option | 18 mm melamine-faced board with movable support pegs | |
| Drawer body | Melamine-faced drawer box or steel drawer box with epoxy-coated runners | |
| Combination lock | Black and silver three-digit mechanical combination lock with manual latch | |
| Support legs | Injection-molded white cylindrical plastic legs with floor-contact pads | |
| Hardware and hinges | Steel concealed hinge, lock strike and zinc-plashed fixings |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Locking and storage function | Three-digit mechanical combination lock secures the upper drawer and is specified to lock the lower compartment simultaneously; verify linked-latch geometry before purchase. | |
|---|---|---|
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Individual workstation setting | Place beside a desk for personal belongings, stationery and documents where a compact lockable cabinet is required. | |
|---|---|---|
| Small office or clinic setting | Use at reception, staff room or consultation area for confidential small items and daily office supplies. |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.9 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
