Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 900 x 400 x 850 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 38 kg | |
|---|---|---|
| Top distributed load | 40 kg | |
| Shelf distributed load | 20 kg per shelf | |
| Door load per hinge | 5 kg | |
| Storage capacity | 0.236 cubic metres | |
| Recommended occupancy | 2 doors and 2 adjustable shelves | |
| Hinge cycle rating for procurement | 50,000 open-close cycles | |
| Drawer slide durability | Not applicable | |
| Warranty target | 3 years | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Carcass panels | 18 mm melamine-faced particleboard in white, using visible square side and base construction | |
|---|---|---|
| Door panels | Two 18 mm light oak-grain melamine panels with straight edges and flush vertical reveal | |
| Top panel | 25 mm light oak-look melamine panel with a matching square edge | |
| Accent strip | Dark grey laminated or PVC decorative rail running across the full door width | |
| Back panel | 8 mm melamine or hardboard back panel fitted into the rear carcass groove | |
| Adjustable shelves | Two 18 mm melamine shelves with metal shelf pins and 32 mm vertical hole spacing | |
| Hinges | Four concealed 35 mm cup hinges, two per door, with 100 degree opening angle | |
| Base feet | Two integrated board or plastic corner supports creating a 50 mm front recess |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Door storage access | Two full-height hinged doors swing open independently to provide access to an 850 mm wide interior | |
|---|---|---|
| Internal shelf adjustment | Two shelves adjust on 32 mm-spaced metal pins, producing storage compartments from 220 to 520 mm high | |
| Floor installation | Freestanding cabinet rests on two front corner supports and a rear base panel; wall anchor is recommended for seismic or high-use areas |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Carton dimensions | 980 x 470 x 150 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office support storage | Suitable beside workstations or in a print/copy area for binders, stationery, consumables and personal work items | |
|---|---|---|
| Pantry or breakout storage | Suitable for cups, packaged supplies and service items in a staff pantry when fitted with wipe-clean melamine shelves |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.9 Storage Units |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
