Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 3000 x 3000 x 2800 mm | |
|---|---|---|
| Center pole diameter | 48 mm | |
| Center pole wall thickness | 2.0 mm | |
| Canopy overhang from pole center | 1500 mm | |
| Under-canopy clearance height | 2200 mm | |
| Support rib count | 8 units | |
| Canopy fabric thickness | 0.5 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total assembled product weight | 59 kg | |
|---|---|---|
| Weighted base static weight | 50 kg | |
| Recommended static load capacity under shade | 4 people | |
| Canopy UPF sun protection rating | UPF50+ | |
| Wind resistance rating (properly secured) | Grade 5 | |
| Crank mechanism open/close cycle rating | 1000 cycles | |
| Fabric water column resistance | 300 mm | |
| Frame rust resistance service life | 3 years | |
| Round weighted base diameter | 500 mm | |
| Round weighted base thickness | 100 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Canopy fabric | 280g/sqm solution-dyed dark green polyester | |
|---|---|---|
| Center support pole | Powder-coated silver finish aluminum alloy | |
| Support ribs | 12mm diameter powder-coated iron | |
| Weighted base | Solid natural granite round disc | |
| Lift mechanism hardware | Zinc-plated steel crank and gear assembly | |
| Pole fasteners | Stainless steel tightening screws and adjustment collars | |
| Canopy stitching | High-tenacity polyester thread | |
| Canopy apex vent | Reinforced mesh polyester vent | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Canopy lift operation | Hand crank mechanism mounted on mid-pole | |
|---|---|---|
| Canopy tilt adjustment | Push-button collar tilt, 30 degree maximum tilt angle | |
| Pole height adjustment | 2-position spring-loaded collar height lock | |
| Base attachment | Set-screw tightening clamp on pole base socket | |
| Canopy wind venting | 100mm diameter apex air vent | |
| Sectional pole assembly | 2-piece pole with slip-fit connection | |
| Canopy removal | Velcro-attached canopy to rib ends | |
| Tilt lock function | Spring-loaded tilt lock pin | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Commercial outdoor dining | Suitable for cafe, restaurant, and milk tea shop outdoor seating | |
|---|---|---|
| Residential courtyard use | Ideal for private garden, patio, or poolside seating | |
| Outdoor event setup | Applicable for market stalls, community events, and pop-up displays | |
| Coastal outdoor areas | Suitable for seaside locations when properly secured | |
| Smoking shelter areas | Provides consistent shade for outdoor designated smoking zones | |
| Hotel poolside deployment | Appropriate for hotel resort pool lounge areas |
EU Market Access Requirements* EN Standards
| Outdoor furniture performance for umbrellas | EN 1176:2017 | |
|---|---|---|
| Textile UV protection performance | EN 13758:2003 |
Standards applicable to China-market projects
| Outdoor furniture structural safety | GB 28007 | |
|---|---|---|
| Textile color fastness to light | GB/T 8427 |
This product must meet the following technical requirements: 1. Outdoor furniture structural safety: GB 28007; 2. Textile color fastness to light: GB/T 8427; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
