Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 3050 x 3050 x 2650 mm | |
|---|---|---|
| Canopy span diameter | 3050 mm | |
| Support pole outer diameter | 48 mm | |
| Cantilever arm horizontal projection | 1600 mm | |
| Under-canopy clearance height | 2200 mm | |
| Canopy rib length | 1525 mm | |
| Crank handle height above ground | 1500 mm | |
| Top vent diameter | 300 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total product weight including base | 170 kg | |
|---|---|---|
| Recommended maximum static stability load | 120 kg base weight | |
| Effective shade coverage area | 7.3 m² | |
| Canopy fabric areal density | 250 g/m² | |
| Fabric fade resistance rating | Grade 4 at 1000 hours | |
| Recommended safe operating wind speed | 38 km/h | |
| Seam tensile strength | 180 N | |
| Frame corrosion resistance | 500 hours salt spray | |
| Standard warranty period | 1 year | |
| Square weighted base dimensions | 520 x 520 x 300 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Vertical support pole | 48mm diameter 1.5mm thick powder-coated steel | |
|---|---|---|
| Curved cantilever arm | 42mm diameter 1.5mm thick powder-coated steel | |
| Canopy support ribs | 8 pieces 18mm diameter powder-coated steel ribs | |
| Canopy fabric | 250g/m² PU-coated solution-dyed polyester | |
| Top vent panel | Polyester mesh fabric | |
| Weighted base | HDPE shell filled with high-density concrete | |
| Adjustment hardware | Zinc-plated steel crank, tilt locks and rotation joints | |
| Canopy edge binding | 15mm wide polyester webbing | |
| Closure strap | 25mm wide hook-and-loop polyester strap | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Canopy opening mechanism | Hand crank operated continuous lift | |
|---|---|---|
| Canopy tilt adjustment | 5-position lockable tilt up to 45 degrees | |
| Pole rotation function | 360-degree foot-pedal controlled rotation | |
| Wind ventilation feature | Single top air vent | |
| Canopy securing feature | Hook-and-loop closure strap | |
| Height adjustment option | 2-position telescopic pole height lock | |
| Arm bracing structure | Dual diagonal steel support struts | |
| Base mounting design | Fixed pole socket with bolted connection | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential patio use | Covers 4-seat outdoor dining or lounge sets for backyard shade | |
|---|---|---|
| Commercial outdoor seating | Suitable for café, restaurant or beer garden outdoor seating areas | |
| Balcony shade application | Fits large balconies with sufficient clearance for rotating canopy | |
| Garden event use | Provides portable shade for small outdoor gatherings or poolside areas | |
| Target user group | Homeowners, commercial property operators, landscape contractors | |
| Recommended placement surface | Flat concrete, stone deck or paved patio surfaces | |
| Seasonal use recommendation | Suitable for spring, summer and fall outdoor use |
EU Market Access Requirements* EN Standards
| Outdoor furniture mechanical safety | EN 581 | |
|---|---|---|
| Textile UV protection performance | EN 13758 |
Standards applicable to China-market projects
| Outdoor furniture umbrella safety | GB 28478 | |
|---|---|---|
| Textile color fastness to light | GB/T 8427 | |
| Metal coating corrosion resistance | GB/T 1771 |
This product must meet the following technical requirements: 1. Outdoor furniture umbrella safety: GB 28478; 2. Textile color fastness to light: GB/T 8427; 3. Metal coating corrosion resistance: GB/T 1771; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
