Automatic mm / inch conversion · Core engineering specifications
| overall assembled dimensions | 3000 x 3660 x 2740 mm | |
|---|---|---|
| vertical support pole diameter | 61 mm | |
| canopy valance height | 150 mm | |
| canopy rib count | 8 units | |
| undercanopy clearance height | 2200 mm | |
| cantilever arm horizontal overhang | 1200 mm | |
| top vent flap dimensions | 2400 x 150 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| umbrella net weight (without fillable base) | 23 kg | |
|---|---|---|
| shade capacity | 8 people | |
| required filled base counterweight | 104 kg | |
| wind speed rating for safe operation | 48 km/h | |
| canopy fabric weight | 240 gsm | |
| fabric water repellency rating | 800 Pa | |
| crank mechanism operation cycles | 1000 cycles | |
| structural limited warranty | 2 years | |
| flat weighted base dimensions | 1000 x 760 mm | |
| Reference Static Load | 150 kg depending on category |
Core acceptance fields · Panels / hardware / frame / upholstery
| support pole frame | 1.5mm thick powder-coated steel | |
|---|---|---|
| canopy support ribs | Powder-coated steel ribs | |
| canopy fabric | 240 gsm UV-treated polyester | |
| valance edge trim | Reinforced stitched polyester binding | |
| crank and tilt hardware | Zinc-plated steel with nylon grip handle | |
| cantilever joint assembly | Die-cast aluminum pivot joints | |
| base platform | HDPE fillable weighted stand | |
| top vent mesh | Breathable open-weave polyester | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| canopy open/close operation | Hand crank lift mechanism | |
|---|---|---|
| canopy tilt adjustment | Continuous crank tilt up to 180 degrees | |
| canopy rotation | 360 degree rotational pivot | |
| wind venting | Integrated top air vent | |
| storage securing | Fabric tie strap fastens closed canopy | |
| base fill option | Sand or water fillable HDPE base | |
| tool-free assembly | Knock-down frame with quick-connect hardware | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| residential patio use | Covers outdoor dining sets for backyard decks and garden patios | |
|---|---|---|
| commercial outdoor seating | Suitable for cafe, poolside and beer garden seating areas | |
| poolside lounge coverage | Provides shaded space over chaise lounge sets near swimming pools | |
| market event vendor use | Portable shade for outdoor market stalls and event booths | |
| temporary event setup | Quick assembly for wedding, party and pop-up event seating |
EU Market Access Requirements* EN Standards
| outdoor furniture mechanical safety | EN 581:2019 |
|---|
Standards applicable to China-market projects
| outdoor furniture structural safety | GB 28478 | |
|---|---|---|
| textile UV performance | GB/T 18830 |
This product must meet the following technical requirements: 1. outdoor furniture structural safety: GB 28478; 2. textile UV performance: GB/T 18830; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
