Dark Green Double-Top Offset Cantilever Patio Umbrella with Scalloped White Trim and Square Weighted Base (model OCP-SQ300-DG-WT) is listed under Patio / Outdoor Umbrella. Dimensions: 3000 × 3000 × 2700 mm. Materials: 1.8mm thick aluminum alloy, dark brown powder-coated finish. Load capacity: 150 kg depending on category. Product Features: outdoor,furniture,cantilever,structure,double-vented,canopy,scalloped,freestanding. This page consolidates 6 groups of specifications, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | JINQIU | Model | OCP-SQ300-DG-WT |
| Overall dimensions (W × D × H) | 3000 × 3000 × 2700 mm | main pole diameter | 65 mm |
| canopy valance height | 150 mm | double-top vent dimensions | 900 x 900 mm |
| minimum clearance under canopy edge | 2000 mm | rib length per canopy segment | 1550 mm |
| Primary Component Thickness | 40 mm according to load-bearing role | Hardware / Moving-part Clearance | 5 mm operating clearance |
| total unit weight with base | 92 kg | recommended static counterweight | 125 kg |
| fabric UV protection rating | UPF50+ | maximum safe operating wind speed | 48 km/h |
| fabric water resistance | 1000 mm hydrostatic head | shade coverage area | 9 m² |
| frame rust resistance lifespan | 5 years | fabric fade resistance warranty | 3 years |
| weighted base dimensions | 1000 x 1000 x 80 mm | Reference Static Load | 150 kg depending on category |
| main support pole | 1.8mm thick aluminum alloy, dark brown powder-coated finish | canopy ribs (8 pieces) | 1.2mm thick powder-coated steel, reinforced joint brackets |
| main canopy fabric | 300gsm solution-dyed polyester, PU waterproof coating | valance trim | White woven polyester binding along scalloped wavy edge |
| double vent panel | Matching 300gsm polyester mesh-reinforced vent top | weighted base | Cast stone/composite square slab with non-slip foot pads |
| crank mechanism | Zinc-plated steel internal gears, plastic hand crank handle | support arm bracing | Triangular powder-coated steel strut frame for wind stability |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | Reference Finish / Color Count | Recommended 6finish options |
| canopy opening/closing | Hand-crank operated lift mechanism with auto-lock when fully open | canopy tilt adjustment | 6-position angle adjustment via pole locking handle, 45° maximum tilt |
| rotation function | 360° horizontal rotation via foot-operated pedal lock release | double-top vent function | Passive airflow vent to reduce wind lift and canopy sway |
| base mounting | Freestanding weighted base, no permanent ground anchoring required for residential use | height adjustment | 3 vertical height positions via pole locking pins, 200mm total adjustment range |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable | Reference Package Count | 1 set / 2 cartons |
| Reference Assembly Time | 40 minutes per set | Reference Packaging Volume | 0.8 m³/set |
| Reference Packaged Gross Weight | 120 kg/set | residential patio use | Suitable for backyard decks, poolside patios, and garden seating areas |
| commercial outdoor seating | Appropriate for cafe, restaurant, and hotel outdoor dining sets | all-weather outdoor installation | Designed for permanent outdoor placement with rust-resistant frame and waterproof fabric |
| seasonal storage compatible | Can be disassembled or closed with attached strap for off-season storage | paired furniture recommendation | Matches 4-seat round/square patio dining sets or 3-seat outdoor lounge sets |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 3000 × 3000 × 2700 mm | |
|---|---|---|
| main pole diameter | 65 mm | |
| canopy valance height | 150 mm | |
| double-top vent dimensions | 900 x 900 mm | |
| minimum clearance under canopy edge | 2000 mm | |
| rib length per canopy segment | 1550 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| total unit weight with base | 92 kg | |
|---|---|---|
| recommended static counterweight | 125 kg | |
| fabric UV protection rating | UPF50+ | |
| maximum safe operating wind speed | 48 km/h | |
| fabric water resistance | 1000 mm hydrostatic head | |
| shade coverage area | 9 m² | |
| frame rust resistance lifespan | 5 years | |
| fabric fade resistance warranty | 3 years | |
| weighted base dimensions | 1000 x 1000 x 80 mm | |
| Reference Static Load | 150 kg depending on category |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| main support pole | 1.8mm thick aluminum alloy, dark brown powder-coated finish | |
|---|---|---|
| canopy ribs (8 pieces) | 1.2mm thick powder-coated steel, reinforced joint brackets | |
| main canopy fabric | 300gsm solution-dyed polyester, PU waterproof coating | |
| valance trim | White woven polyester binding along scalloped wavy edge | |
| double vent panel | Matching 300gsm polyester mesh-reinforced vent top | |
| weighted base | Cast stone/composite square slab with non-slip foot pads | |
| crank mechanism | Zinc-plated steel internal gears, plastic hand crank handle | |
| support arm bracing | Triangular powder-coated steel strut frame for wind stability | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| canopy opening/closing | Hand-crank operated lift mechanism with auto-lock when fully open | |
|---|---|---|
| canopy tilt adjustment | 6-position angle adjustment via pole locking handle, 45° maximum tilt | |
| rotation function | 360° horizontal rotation via foot-operated pedal lock release | |
| double-top vent function | Passive airflow vent to reduce wind lift and canopy sway | |
| base mounting | Freestanding weighted base, no permanent ground anchoring required for residential use | |
| height adjustment | 3 vertical height positions via pole locking pins, 200mm total adjustment range | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| residential patio use | Suitable for backyard decks, poolside patios, and garden seating areas | |
|---|---|---|
| commercial outdoor seating | Appropriate for cafe, restaurant, and hotel outdoor dining sets | |
| all-weather outdoor installation | Designed for permanent outdoor placement with rust-resistant frame and waterproof fabric | |
| seasonal storage compatible | Can be disassembled or closed with attached strap for off-season storage | |
| paired furniture recommendation | Matches 4-seat round/square patio dining sets or 3-seat outdoor lounge sets |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
