Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 3050 x 3050 x 2840 mm | |
|---|---|---|
| Eaves clear height | 1950 mm | |
| Upper vented roof dimensions | 1200 x 1200 mm | |
| Corner support post cross-section | 80 x 80 mm | |
| Curtain panel height | 1930 mm | |
| Interior clear floor area | 9.3 m² | |
| Frame post wall thickness | 1.2 mm | |
| Canopy fabric overhang beyond frame | 150 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Static frame load capacity | 500 kg | |
|---|---|---|
| Maximum occupant capacity | 6 people | |
| Canopy UV block rate | 99% | |
| Wind resistance rating | 40 km/h | |
| Unit net weight | 52 kg | |
| Fabric waterproof rating | 300 mm water column | |
| Frame rust protection lifespan | 3 years | |
| Manufacturer warranty period | 1 year | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Corner support posts | 1.2mm thick powder-coated black steel | |
|---|---|---|
| Roof frame trusses | 0.8mm thick powder-coated steel tubing | |
| Main canopy fabric | 300D UV-resistant lime green polyester | |
| Upper vent canopy fabric | 300D lime green polyester matching main roof | |
| Privacy curtain panels | 180D lime green polyester | |
| Anchor hardware | Galvanized steel ground stakes | |
| Curtain attachment fasteners | Nylon hook-and-loop straps | |
| Frame connection brackets | 1.5mm thick pressed steel with black powder coat | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Double-tier vented roof design | Raised upper canopy allows hot air escape and reduces wind uplift | |
|---|---|---|
| Perimeter privacy curtain system | Four removable side panels slide/attach to frame for full enclosure | |
| Ground anchoring system | Galvanized stakes secure frame feet to paved/grass surfaces for stability | |
| Curtain open/close mechanism | Panels tie back to corner posts or close fully for privacy and shade | |
| Water drainage design | Sloped main canopy directs rainwater to roof edges to prevent pooling | |
| Tool-assisted assembly | Bolt-together frame with pre-drilled holes for 2-person assembly | |
| Canopy replacement compatibility | Fabric roof attaches with hook-and-loop straps for easy seasonal replacement | |
| Weather resistance function | Fabric provides sun shade and light rain protection for outdoor dining | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential patio use | Suitable for backyard paved patio areas, shelters 4-person outdoor dining sets | |
|---|---|---|
| Garden leisure space | Ideal for lawn-adjacent garden seating zones for shade and privacy | |
| Outdoor catering events | Provides temporary shaded seating for small outdoor gatherings and parties | |
| Seasonal outdoor installation | Designed for warm-season use, removable canopy for winter storage | |
| Poolside shade stations | Works for pool deck areas offering UV protection for lounging spaces | |
| Balcony large terrace use | Fits large open residential terraces for semi-permanent outdoor shelter |
EU Market Access Requirements* EN Standards
| EN 13782:2015 | Applies to structural safety requirements for temporary outdoor shelter frames | |
|---|---|---|
| EN 15619:2014 | Applies to water penetration resistance testing for coated canopy fabrics |
Standards applicable to China-market projects
| GB/T 21884-2008 | Applies to UV stability testing of outdoor textile canopy fabrics | |
|---|---|---|
| GB/T 4288-2018 | Applies to fabric color fastness testing for outdoor dyed materials | |
| GB/T 1766-2008 | Applies to powder coating corrosion resistance rating for steel frames |
This product must meet the following technical requirements: 1. GB/T 21884-2008: Applies to UV stability testing of outdoor textile canopy fabrics; 2. GB/T 4288-2018: Applies to fabric color fastness testing for outdoor dyed materials; 3. GB/T 1766-2008: Applies to powder coating corrosion resistance rating for steel frames; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
