Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 4000 x 3000 x 2870 mm | |
|---|---|---|
| Canopy edge clearance from ground | 2100 mm | |
| Support pole diameter | 102 mm | |
| Valance overhang depth | 200 mm | |
| Double-top vent gap height | 300 mm | |
| Support arm angle from vertical | 25 degrees | |
| Base footprint width (distance between dual pole bases) | 1800 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Recommended minimum counterweight per base | 91 kg | |
|---|---|---|
| Total recommended unit weight with filled bases | 212 kg | |
| Wind speed rating for safe use | 48 km/h | |
| Canopy fabric UPF protection rating | 50+ | |
| Fabric water repellency rating | AATCC 22 grade 4 | |
| Recommended number of users shaded | 8 | |
| Frame static load rating | 250 kg | |
| Fade resistance service life | 3 years | |
| Single weighted base diameter | 800 mm | |
| Reference Static Load | 150 kg depending on category |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main canopy fabric | 280 gsm PU-coated solution-dyed polyester | |
|---|---|---|
| Double-top vent panel fabric | 240 gsm polyester mesh | |
| Support poles and arms | 1.8 mm thick powder-coated aluminum alloy | |
| Canopy support ribs | Powder-coated steel, 8 total ribs | |
| Weighted bases | Concrete-filled HDPE plastic shells, round shape | |
| Scalloped valance trim | Stitched polyester with reinforced hem | |
| Crank adjustment mechanism | Zinc-plated steel crank with plastic handle | |
| Fastener hardware | Stainless steel bolts and brackets | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Canopy operation | Hand-crank open and close mechanism | |
|---|---|---|
| Rotation function | 360 degree horizontal rotation around vertical pole axis | |
| Height adjustment | 5 positional height settings with lockable lever | |
| Tilt adjustment | Multi-angle tilt to track sun position, 3 lock positions | |
| Double-top vent function | Passive wind ventilation to reduce uplift force | |
| Base installation | Freestanding weighted bases, no permanent floor anchoring required | |
| Canopy closure | Manual crank-fold for storage during inclement weather | |
| Locking mechanism | Positive lock at each height and tilt position to prevent drift | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential patio use | Covers outdoor dining sets for backyard decks and garden seating areas | |
|---|---|---|
| Commercial outdoor seating | Suitable for cafe, restaurant and resort poolside seating zones | |
| Event temporary shade | Provides portable shade for outdoor markets, weddings and corporate events | |
| Indoor display use | Suitable for showroom and exhibition display of outdoor leisure products | |
| Coastal outdoor application | Corrosion-resistant hardware and coated frame suit salt-air environments | |
| Seating area shade placement | Positioned over lounge sets or dining sets without pole blocking access |
EU Market Access Requirements* EN Standards
| Outdoor furniture mechanical safety | EN 581:2019 | |
|---|---|---|
| Textile UV protection testing | EN 13758:2001+A1:2006 |
Standards applicable to China-market projects
| Outdoor furniture umbrella structural safety | GB/T 33254 | |
|---|---|---|
| Textile UV protection performance | GB/T 18830 | |
| Metal furniture coating adhesion | GB/T 4893.4 |
This product must meet the following technical requirements: 1. Outdoor furniture umbrella structural safety: GB/T 33254; 2. Textile UV protection performance: GB/T 18830; 3. Metal furniture coating adhesion: GB/T 4893.4; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
