PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	3000 × 3000 × 2600 mm
Primary Component Thickness	40 mm according to load-bearing role
Hardware / Moving-part Clearance	5 mm operating clearance

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended base weight (filled, for wind stability)	120 kg
Canopy wind resistance rating (properly anchored)	39 km/h
Fabric UV protection factor (UPF)	50+
Water column pressure resistance of canopy	300 mm
Product net weight (without filled base weights)	28 kg
Recommended maximum seating coverage	6 people
Tilt mechanism crank operating cycles	3000 cycles
Reference Static Load	150 kg depending on category
Moving-part Durability Reference	Acceptance target 50000 cycles
Recommended Procurement Warranty	Structure 5 years; hardware 3 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Canopy outer/top surface	250gsm solution-dyed polyester with PU water-repellent coating
Canopy inner/underside surface	Matte taupe solution-dyed polyester, double-stitched seams
Internal support ribs	18mm diameter powder-coated steel ribs, 8 total ribs
Vertical support pole	76mm diameter matte gray powder-coated aluminum, 1.8mm wall thickness
Cantilever support arms	Rectangular powder-coated aluminum arms with reinforced joint brackets
Tilt and crank mechanism	Die-cast aluminum housing with steel crank handle and internal gear set
Cross base frame	Galvanized steel cross arms with powder-coated gray finish, designed for weighted slab or sandbag installation
Canopy top vent	Mesh-reinforced polyester wind vent at canopy apex
Joint hardware	Stainless steel bolts and locking knobs for angle adjustment
Primary Connector Specification	Reference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color Count	Recommended 6finish options

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

360-degree canopy rotation	Foot-activated rotation lock allows full 360-degree horizontal repositioning of shade without moving the base
Crank-operated tilt adjustment	Manual crank adjusts canopy tilt angle up to 45 degrees from vertical to block low-angle sun
Easy open/close operation	Integrated crank mechanism opens and closes canopy smoothly in 12 full crank rotations
Cross base weight compatibility	Base accepts four separate 30kg concrete or resin weight plates on cross arms for stable anchoring
Wind vent pressure relief	Apex wind vent reduces canopy uplift in gusty conditions by allowing air flow through the top of the canopy
Canopy angle locking	Automatic angle lock secures canopy at 5 preset tilt positions to prevent unintended movement
Removable canopy for cleaning	Canopy attaches to ribs via fabric pockets and velcro straps for easy removal and machine washing
Tilt adjustment arm length	900 mm
Reference Adjustment / Operating Range	100 mm or 120° where applicable

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Shipping carton dimensions (L x W x H)	1550 x 320 x 180 mm
Gross shipping weight (without base weights)	32 kg
Assembly time (2 people, basic tools included)	35 minutes
20ft GP container loading quantity	310 units
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Packaging Volume	0.8 m³/set
Reference Packaged Gross Weight	120 kg/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Residential patios and backyards	Provides flexible shade over outdoor dining sets, lounge seating, or hot tub areas without center pole obstruction
Commercial outdoor cafe seating	Covers small bistro table groupings for restaurant sidewalk or patio dining areas
Poolside lounge areas	UV-resistant water-repellent canopy blocks sun over chaise lounge seating near swimming pools
Balcony and rooftop terrace use	Compact cross base fits on paved elevated outdoor surfaces without permanent installation
Garden event temporary shade	Portable design supports temporary setup for backyard parties, barbecues, or small outdoor events
Seasonal outdoor storage compatibility	Folds compactly for vertical storage in garages or garden sheds during off-season months

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OFS-CSQ-3000-ALU

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OFS-CSQ-3000-ALU

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OFS-CSQ-3000-ALUOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Square Cantilever Offset Patio Umbrella with Crank Tilt and Cross Base (model OFS-CSQ-3000-ALU, unbranded) features a clean, functional cantilever silhouette that positions shade entirely to the side of its support structure, eliminating the center pole obstruction common to traditional patio umbrellas. The 3000mm square canopy sits at a total height of 2600mm, with a matte taupe underside and mesh-reinforced wind vent at its apex, paired with a matte gray powder-coated aluminum vertical pole and matching rectangular cantilever arms for a sleek, understated outdoor aesthetic. The galvanized steel cross base sits flush to paved surfaces, creating a low-profile foundation without bulky, protruding hardware. Durable, weather-resistant construction forms the core of the umbrella’s design. The 250gsm solution-dyed polyester canopy carries a PU water-repellent coating, with double-stitched seams for long-term durability, supported by 8 powder-coated steel ribs and reinforced joint brackets on the aluminum cantilever arms. The vertical pole measures 76mm in diameter with 1.8mm wall thickness, connected to the galvanized steel cross base via stainless steel bolts and locking knobs. The tilt and crank mechanism is housed in die-cast aluminum, with a steel crank handle and internal gear set, tested to support 3000 crank operating cycles with 5mm operating clearance for moving parts. The entire structure weighs 28kg without filled base weights. User-centric functions support flexible, easy shade adjustment. A foot-activated lock enables full 360-degree horizontal canopy rotation without repositioning the base, while the manual crank adjusts tilt up to 45 degrees from vertical across 5 preset locked positions to block low-angle sun, requiring 12 full rotations to smoothly open or close the canopy. The apex wind vent allows air flow to reduce uplift during gusty conditions, and the canopy attaches to ribs via fabric pockets and velcro straps for easy removal and machine washing. When properly anchored with 120kg of filled base weight across the cross base’s four compatible 30kg weight plates, the canopy delivers UPF 50+ UV protection, 300mm water column pressure resistance, and wind resistance up to 39 km/h, with coverage for up to 6 people. This umbrella suits a wide range of outdoor settings, including residential patios, backyards, and poolside lounge areas where it covers dining sets, seating groups, or hot tubs; commercial cafe sidewalk seating for small bistro table groupings; elevated balconies and rooftop terraces where permanent installation is not feasible; and temporary garden events such as parties or barbecues. It folds compactly for vertical off-season storage in garages or garden sheds. For procurement, note that the product ships in 2 cartons per set, with a gross shipping weight of 32kg, and requires 40 minutes of assembly per set with two people using included basic tools. A 20ft GP container holds 310 units, and purchasers must source compatible 30kg concrete or resin weight plates separately, as base weights are not included with the umbrella, to ensure rated wind stability during use.
