Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint (umbrella deployed) | 2740 x 2740 x 2515 mm | |
|---|---|---|
| Round dining table dimensions | 900 mm diameter x 750 mm height | |
| Table central umbrella hole diameter | 51 mm | |
| Dining armchair overall dimensions | 680 mm W x 660 mm D x 910 mm H | |
| Chair seat height from ground | 480 mm | |
| Chair seat dimensions | 520 mm W x 460 mm D | |
| Chair armrest height from ground | 660 mm | |
| Umbrella canopy diameter | 2740 mm | |
| Umbrella pole diameter | 38 mm | |
| Table pedestal base diameter | 610 mm | |
| Knee clearance under table apron | 660 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total set weight (table + 2 chairs + umbrella) | 56 kg | |
|---|---|---|
| Per-chair static weight capacity | 180 kg | |
| Round table top static load capacity | 90 kg | |
| Recommended seating capacity | 2 adults | |
| Powder coat weather durability | 500 hours salt spray resistance | |
| PE wicker UV fade resistance | 1000 hours Xenon arc exposure | |
| Umbrella wind stability rating | 24 km/h | |
| Manufacturer limited warranty period | 2 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table frame and pedestal base | Cast aluminum with dark bronze powder-coated finish | |
|---|---|---|
| Table top surface | Cast aluminum with textured dark bronze powder coat | |
| Chair structural frames | Cast aluminum tubing with dark bronze powder-coated finish | |
| Chair seat and back panels | Weather-resistant PE wicker with herringbone woven pattern | |
| Chair foot glides | Nylon non-marking adjustable leveler feet | |
| Umbrella pole and internal ribs | Powder-coated bronze finished steel | |
| Umbrella canopy fabric | Solution-dyed polyester cream/off-white fabric | |
| Assembly hardware | Zinc-plated stainless steel fasteners | |
| Table top edge trim | Cast aluminum integrated rolled edge | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Table umbrella pass-through | Central 51mm hole accommodates standard patio umbrella poles | |
|---|---|---|
| Chair adjustable levelers | Screw-adjustable nylon feet compensate for uneven lawn or patio surfaces | |
| All-weather construction performance | Rust, fade, and crack resistant materials designed for year-round outdoor use | |
| Umbrella manual lift operation | Manual push-up lift with locking ring to set canopy height | |
| Knock-down assembly design | Flat-pack shipping with included hex key and hardware for 1-person assembly | |
| Chair stackable storage | Chairs are not stackable, fixed frame construction | |
| Surface cleaning compatibility | Smooth powder coat and wicker surfaces wipe clean with mild soap and water | |
| Table base weight compatibility | Pedestal design supports optional 18kg umbrella weight base (not included) | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential backyard lawn | Freestanding set for casual outdoor meals and relaxation on grass yards | |
|---|---|---|
| Small balcony or terrace | Compact 2-person footprint fits apartment patios or compact outdoor spaces | |
| B&B outdoor guest seating | Durable decorative design for boutique hospitality patio guest dining | |
| Poolside lounge seating | Rust-resistant construction tolerates poolside humidity and chlorine exposure | |
| Garden courtyard dining | Ornate cast scroll base complements formal garden landscaping | |
| Cafe sidewalk seating | Compact 2-person configuration works for small commercial outdoor bistro seating |
EU Market Access Requirements* EN Standards
| Outdoor furniture seating safety | EN 581:2017 | |
|---|---|---|
| Outdoor table mechanical performance | EN 581:2017 |
Standards applicable to China-market projects
| Outdoor furniture structural safety | GB 28007 | |
|---|---|---|
| Metal furniture coating performance | GB/T 3324 | |
| Textile fabric color fastness | GB/T 8427 |
This product must meet the following technical requirements: 1. Outdoor furniture structural safety: GB 28007; 2. Metal furniture coating performance: GB/T 3324; 3. Textile fabric color fastness: GB/T 8427; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
