Automatic mm / inch conversion · Core engineering specifications
| Overall combination dimensions | 3200 x 450 x 2000 mm | |
|---|---|---|
| Central TV stand dimensions | 2200 x 450 x 500 mm | |
| Left tall display cabinet dimensions | 450 x 420 x 2000 mm | |
| Right stepped side cabinet dimensions | 550 x 400 x 900 mm | |
| Central TV stand top height | 500 mm | |
| Cabinet door panel thickness | 18 mm | |
| Tempered glass panel thickness | 5 mm | |
| Back panel thickness | 9 mm | |
| Adjustable shelf thickness | 18 mm | |
| Cable management opening diameter | 60 mm | |
| Toe kick height | 80 mm | |
| Open shelf clear height (tall cabinet) | 300 mm | |
| Drawer internal usable height | 150 mm | |
| Glass door display shelf clear height | 280 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm |
Net weight / load capacity / users / durability
| TV stand top static load capacity | 80 kg | |
|---|---|---|
| Total product net weight | 200 kg | |
| Supported maximum TV screen size | 85 inches | |
| Hinge cycle rating | 80000 open/close cycles | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Main structure warranty | 3 years | |
| Hardware component warranty | 5 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main structural frame | Imported solid rubberwood, walnut-toned clear lacquer finish | |
|---|---|---|
| Cabinet door panels | Solid rubberwood frame with recessed panel design, matching lacquer finish | |
| Display door panels | 5mm clear tempered glass set in solid rubberwood frames | |
| Drawer components | Solid rubberwood drawer fronts, plywood drawer boxes with dovetail joinery | |
| Shelf panels | 18mm thick solid rubberwood, adjustable via metal shelf pins | |
| Back panels | 9mm thick rubberwood veneer plywood, sealed with matching lacquer | |
| Hardware components | Zinc alloy soft-close hinges, cold-rolled steel side-mount drawer slides | |
| Surface finish | Nitrocellulose lacquer topcoat, matte walnut tone, scratch-resistant top layer | |
| Feet/base | Solid rubberwood integrated plinth base, floor protection felt pads | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | 2 lower central drawers, 2 side cabinet doors, 1 tall glass door, 1 side glass door, 6 open shelves | |
|---|---|---|
| Cable management | Rear 60mm diameter cable port on central TV stand for AV and power cords | |
| Adjustable shelving | Tall cabinet and side cabinet shelves adjust in 32mm increments for variable item heights | |
| Soft-close hardware | Door hinges and drawer slides include soft-close damping to prevent slamming | |
| Ventilation design | Rear ventilation gaps behind closed media compartments to prevent device overheating | |
| Modular installation | Three separate cabinet units align to form a seamless asymmetric wall set | |
| Wall anchoring provision | Pre-drilled anti-tip mounting points on tall cabinet rear for wall securing | |
| Toe kick clearance | 80mm recessed toe space along front base for comfortable standing access | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Assembly note | Units are pre-finished, only require leveling and wall anchor installation | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Living room feature wall | Wall-mounted behind primary seating area as combined TV stand and display storage | |
|---|---|---|
| Medium to large apartment spaces | Suits 40sqm living rooms with 3m or wider available wall space | |
| Chinese style interior schemes | Matches traditional and new Chinese home decor with solid wood walnut finish | |
| Mixed storage and display use | Hides media accessories in closed storage, displays books and decor on open/glass shelves | |
| Open plan living areas | Serves as a visual focal point without blocking sightlines in open floor plans | |
| Residential home use | Designed for private homes, not heavy commercial high-traffic environments |
EU Market Access Requirements* EN Standards
| EN 312:2010 | Particleboard specifications, applicable for performance of engineered wood components | |
|---|---|---|
| EN 14749:2016 | Domestic and kitchen storage units and worktops - safety requirements | |
| EN 12521:2015 | Furniture - strength, durability and safety for domestic storage furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural safety and finish quality | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances in wooden furniture | |
| GB/T 4897.3-2015 | Particleboard for furniture use, applicable to engineered wood components | |
| GB/T 11718-2021 | Medium density fiberboard for furniture, applicable if used in non-visible panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural safety and finish quality; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances in wooden furniture; 3. GB/T 4897.3-2015: Particleboard for furniture use, applicable to engineered wood components; 4. GB/T 11718-2021: Medium density fiberboard for furniture, applicable if used in non-visible panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
