Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (fully extended) | 2500 x 400 x 480 mm | |
|---|---|---|
| Retracted overall width | 1500 mm | |
| Central open media shelf internal dimensions | 800 x 360 x 180 mm | |
| Left stacked drawer internal dimensions (per drawer) | 620 x 340 x 130 mm | |
| Right side-by-side drawer internal dimensions (per drawer) | 400 x 340 x 130 mm | |
| Top surface thickness | 30 mm | |
| Carcass side panel thickness | 25 mm | |
| Base leg height | 60 mm | |
| Back panel cable cutout diameter | 60 mm | |
| Rounded corner radius | 50 mm | |
| Drawer front decorative wave groove depth | 5 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top surface maximum static load | 82 kg | |
|---|---|---|
| Per drawer maximum load | 15 kg | |
| Central shelf maximum load | 25 kg | |
| Extension slide cycle rating | 50000 cycles | |
| Drawer slide cycle rating | 30000 cycles | |
| Maximum compatible TV size | 85 inch | |
| Net weight | 90 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main frame and legs | Kiln-dried solid rubberwood with walnut lacquer finish | |
|---|---|---|
| Top surface | Solid wood veneer over engineered wood core, polished scratch-resistant finish | |
| Drawer fronts | Solid wood with embossed wave decorative grooves, matching walnut finish | |
| Drawer boxes | 15mm thick plywood with dovetail joint construction | |
| Drawer slides | Cold-rolled steel three-section full-extension slides, black powder coat | |
| Extension mechanism rails | Heavy-duty galvanized steel telescoping rails | |
| Back panel | 8mm thick MDF with pre-drilled cable management cutouts | |
| Base frame support | Solid wood perimeter stretcher connecting block legs for stability | |
| Finish coating | Low-VOC polyurethane lacquer, semi-gloss sheen | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Dual-side extendable design | Telescoping steel rails extend total width from 1500mm to 2500mm | |
|---|---|---|
| Drawer storage system | Four soft-close drawers: two stacked left, two side-by-side right | |
| Central open media bay | Fixed open shelf for frequently accessed media devices, no door obstruction | |
| Integrated cable management | Pre-cut 60mm cable holes at back of open shelf and top surface | |
| Floor-standing installation | Short solid block legs with non-slip foot pads, no wall mounting required | |
| Rounded anti-collision edges | Curved rounded corners on both end frames to reduce impact injury | |
| Fixed shelf configuration | Central open shelf and base panel are fixed, no adjustable shelving | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential living room placement | Positioned against wall under wall-mounted or tabletop flat-screen TV | |
|---|---|---|
| Media equipment storage | Holds set-top boxes, game consoles, DVD players and media accessories in open and drawer storage | |
| Matching living room sets | Pairs with matching solid wood coffee tables, sideboards and sofa sets in walnut Chinese style | |
| Multi-size TV adaptation | Extendable width fits 55-inch to 85-inch flat-screen televisions for different room sizes | |
| Family home use | Rounded edges and stable frame suitable for households with children and elderly residents | |
| Apartment and villa applications | Available in retracted compact size for small apartments or extended size for large villa living rooms |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic seating and storage furniture | |
|---|---|---|
| EN 717-1:2004 | Wood-based panels – Formaldehyde release determination, applicable for panel components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural safety and finish quality | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wood furniture, applicable for formaldehyde emission control | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for engineered wood core components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural safety and finish quality; 2. GB 18584-2001: Limit of harmful substances in wood furniture, applicable for formaldehyde emission control; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable for engineered wood core components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
