Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2200 x 420 x 480 mm | |
|---|---|---|
| Leg height | 150 mm | |
| Top surface thickness | 12 mm | |
| Carcass panel thickness | 18 mm | |
| Back panel thickness | 5 mm | |
| Central open media shelf internal dimensions | 800 x 380 x 150 mm | |
| Single drawer internal dimensions | 800 x 370 x 120 mm | |
| Side closed cabinet internal dimensions | 600 x 380 x 280 mm | |
| Floor clearance under cabinet | 120 mm | |
| Cable management opening diameter | 60 mm | |
| Recessed pull groove depth | 10 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top surface static load capacity | 80 kg | |
|---|---|---|
| Product net weight | 52 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Recommended maximum TV size | 85 inch | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Top surface | 12mm white sintered stone with polished matte finish | |
|---|---|---|
| Cabinet body | 18mm E0-grade engineered wood with light natural oak veneer | |
| Support legs | Solid rubberwood with natural oak clear varnish finish, tapered angled design | |
| Drawer slides | Cold-rolled steel soft-close full-extension slides, zinc-plated finish | |
| Door hinges | Cold-rolled steel concealed soft-close hinges, nickel-plated finish | |
| Back panel | 5mm high-density fiberboard with oak-melamine finish | |
| Internal shelves | 15mm engineered wood with matching oak veneer, fixed position | |
| Surface coating | UV-cured clear matte varnish on wood surfaces, scratch-resistant | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | 2 side closed cabinet doors, 1 central open media shelf, 2 central drawers | |
|---|---|---|
| Cable management | Rear pre-drilled 60mm openings behind open shelf and cabinets | |
| Drawer operation | Soft-close full-extension drawers with integrated recessed pulls, no external handles | |
| Door operation | Soft-close hinged cabinet doors with integrated recessed edge pulls, no external handles | |
| Ventilation design | 10mm gap around open shelf and rear ventilation slots for AV device heat dissipation | |
| Assembly requirement | Leg attachment and handle hardware installation required, flat-pack delivery | |
| Surface protection | Scratch-resistant and heat-resistant sintered stone top for daily household use | |
| Anti-tip feature | Wall anchor hardware included for securing unit to wall to prevent tipping | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Living room main wall placement | Positioned flush against wall under wall-mounted or freestanding television | |
|---|---|---|
| Small to medium apartment use | Suitable for 30sqm living rooms with 85inch televisions | |
| Media device storage | Central open shelf holds set-top boxes, game consoles and AV receivers | |
| Matching interior styles | Fits Scandinavian, modern minimalist, Japanese wabi-sabi and light luxury decor | |
| Additional use cases | Can be used as a low sideboard in dining areas or entryway console | |
| Recommended paired furniture | Matches light oak coffee tables, fabric sofas and light wood flooring for cohesive design |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops - safety requirements | |
|---|---|---|
| EN 12521:2015 | Furniture - strength, durability and safety for domestic storage furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for cabinet structural performance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances in wood furniture | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for engineered wood carcass panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for cabinet structural performance; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances in wood furniture; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable for engineered wood carcass panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
