Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 420 x 500 mm | |
|---|---|---|
| Leg height | 150 mm | |
| Central open media shelf dimensions | 700 x 380 x 150 mm | |
| Single drawer front dimensions | 530 x 160 mm | |
| Drawer internal depth | 360 mm | |
| Top surface thickness | 25 mm | |
| Carcass panel thickness | 18 mm | |
| Back panel thickness | 9 mm | |
| Floor clearance under unit | 125 mm | |
| Rounded corner radius | 20 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top surface static load capacity | 136 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 open/close cycles | |
| Surface scratch resistance rating | Class 2 | |
| Net product weight | 38 kg | |
| Supported maximum TV size | 85 in | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Top surface | 18mm engineered wood core with light oak wood veneer, matte clear finish | |
|---|---|---|
| Outer frame | Solid rubberwood edge banding, light natural oak finish | |
| Drawer fronts | 15mm MDF core with matte off-white polyurethane paint | |
| Legs | Solid rubberwood tapered cylindrical legs, natural oak finish | |
| Drawer slides | Cold-rolled steel soft-close full-extension glides, zinc-plated finish | |
| Recessed drawer pulls | Integrated groove pulls matching drawer front finish, no protruding hardware | |
| Back panel | 9mm medium-density fiberboard with pre-drilled cable openings, black finish | |
| Internal drawer boxes | 12mm plywood with dovetail joint construction, natural wood finish | |
| Foot pads | Non-slip felt pads on leg bases, 5mm thick | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Drawer operation | Four soft-close drawers with integrated recessed pulls, two stacked left, two stacked right | |
|---|---|---|
| Central media storage | Open horizontal cubby above middle lower drawer for unobstructed AV component placement | |
| Cable management | Two 60mm diameter cable ports in back panel behind open shelf | |
| Ventilation design | 20mm gap between back panel and shelf interior for passive airflow | |
| Floor protection | Felt foot pads on all four legs eliminate contact scuffs on wood or tile flooring | |
| Surface usability | Scratch-resistant matte wipe-clean top supports display of decor items alongside television | |
| Assembly requirement | Knock-down flat pack assembly with included hardware and step-by-step instructions | |
| Matching set compatibility | Matching 1200mm two-drawer coffee table available with identical finish and leg style | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential living rooms | Primary placement against a wall under wall-mounted or stand-mounted flat-screen televisions | |
|---|---|---|
| Apartment and small home spaces | Low-profile 500mm height maintains sight lines in compact open-plan living areas | |
| Scandinavian/modern minimalist interiors | Two-tone oak and off-white finish pairs with light wood and neutral decor schemes | |
| Media equipment storage | Open shelf supports set-top boxes, gaming consoles and soundbars without blocking remote signals | |
| Matching furniture coordination | Pairs with identical-style matching coffee table for cohesive living room set design | |
| Low-height decorative display | Top surface holds framed photos, small plants and decorative objects at ideal viewing height |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops - safety requirements and test methods, applicable for structural stability |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel construction and finish quality inspection | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances in wood furniture, required for formaldehyde emission testing | |
| GB/T 10357.1-2013 | Test of mechanical properties of furniture - strength and durability of tables, applicable for static load testing of top surface |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel construction and finish quality inspection; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances in wood furniture, required for formaldehyde emission testing; 3. GB/T 10357.1-2013: Test of mechanical properties of furniture - strength and durability of tables, applicable for static load testing of top surface; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
