Automatic mm / inch conversion · Core engineering specifications
| Carcass Panel Thickness | 25 mm | |
|---|---|---|
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Total set reference weight | 125 kg | |
|---|---|---|
| Tabletop static load capacity (coffee/TV) | 50 kg | |
| Recommended maximum TV size for stand | 85 in | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main cabinet carcass | 18mm thick particleboard with walnut wood grain laminate | |
|---|---|---|
| Drawer front panels | 15mm thick MDF with matte white thermofoil finish | |
| Support legs | 25mm diameter matte black powder-coated steel, tapered design | |
| Tabletop surface | Walnut grain high-pressure laminate, scratch-resistant top layer | |
| Internal shelf panels | 15mm thick matching walnut particleboard | |
| Drawer slides | Side-mounted 3-section ball-bearing steel slides | |
| Back panel | 3mm thick hardboard with matching dark brown finish | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Extendable TV stand configuration | Modular sectional design, can connect to side cabinet for full L-shaped layout | |
|---|---|---|
| Drawer operation | Push-to-open latch mechanism, no exposed handles, full 300mm extension travel | |
| Open storage access | Forward-facing open cubbies on TV stand and coffee table, no door obstruction for frequently used items | |
| Side cabinet display storage | Two upper open display tiers, one lower closed drawer for concealed storage | |
| Floor clearance design | 150mm under-unit gap enables robot vacuum access and easy floor cleaning | |
| Surface placement | Level laminated tops support stable placement of TVs, tableware, decor and serving items | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential living room use | Coordinated storage set for sofas sized 2.2m to 3m, aligned height for TV viewing | |
|---|---|---|
| Apartment open-plan space | Low-profile two-tone design fits modern compact urban living spaces without visual bulk | |
| Media entertainment setup | Open shelves house AV receivers, game consoles and streaming devices, cable access at rear | |
| Casual serving use | Coffee table height matches standard sofa seat height for snacks, drinks and reading material |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
