Automatic mm / inch conversion · Core engineering specifications
| Overall console dimensions | 2000 x 450 x 450 mm | |
|---|---|---|
| Tapered solid wood leg height | 150 mm | |
| Central drawer unit external width | 900 mm | |
| Open side shelf internal width (each side) | 480 mm | |
| Open side shelf internal depth | 380 mm | |
| Open shelf clearance under apron | 150 mm | |
| Drawer internal dimensions | 860 x 360 x 110 mm | |
| Top panel thickness | 25 mm | |
| Carcass side panel thickness | 18 mm | |
| Rear cable cutout diameter | 60 mm | |
| Floor clearance under lower apron | 120 mm | |
| Rounded top corner radius | 15 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Console net weight | 45 kg | |
|---|---|---|
| Top surface static load capacity | 70 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Recommended maximum TV screen size | 75 in | |
| Surface abrasion resistance | Class 2 (1000 cycles) | |
| Formaldehyde emission level (recommended) | E0 grade | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop | 18mm solid pine/rubberwood core with light oak veneer, matte clear UV finish | |
|---|---|---|
| Tapered legs | Solid rubberwood with natural oiled finish, 40mm diameter at top | |
| Drawer fronts | 18mm solid wood frame with integrated recessed horizontal wood pull | |
| Drawer boxes | Paulownia wood drawer sides with 12mm thickness | |
| Drawer slides | Cold-rolled steel side-mount full-extension slides, zinc-plated finish | |
| Carcass frame and shelves | 15mm engineered wood with matching light wood veneer finish | |
| Back panel | 3mm hardboard with pre-cut cable ventilation openings | |
| Side slatted decorative panels | 10mm solid wood slats with 20mm gap spacing | |
| Foot pads | Non-slip PE plastic pads at leg bases | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Central drawer storage | Full-width central drawer on full-extension slides, opens to full depth for media accessory storage | |
|---|---|---|
| Dual open side shelves | Fixed open bays on left and right sides for AV devices, books and display items | |
| Rear cable management | Two 60mm diameter rear cutouts for AV power and HDMI cable routing | |
| Ventilation openings | Slatted side panels and rear gaps provide passive airflow for active media devices | |
| Freestanding installation | No wall mounting required, rests on 4 tapered legs with floor protection pads | |
| Integrated recessed pulls | Horizontal recessed wood pulls on drawer fronts for flush, handle-free operation | |
| Leveling adjustment | Leg base pads allow 5mm height adjustment for uneven floors | |
| Surface protection | Matte clear finish resists water rings and minor scratches from daily use | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Primary use case | Living room wall-positioned media console for flat-screen TV and AV equipment placement | |
|---|---|---|
| Matching furniture compatibility | Pairs with coordinating single-drawer slatted-shelf coffee table for cohesive Japandi/Scandinavian living room sets | |
| Suitable room size | Works in small to medium living rooms (25sqm) with 3seater sofas | |
| Storage use cases | Stores media remotes, game consoles, books, and decorative objects in drawer and open shelves | |
| Style compatibility | Complements light wood, minimalist, Japanese, and mid-century modern interior design schemes | |
| Floor type compatibility | Suitable for hardwood, laminate, tile and low-pile carpeted floors with non-slip foot pads | |
| Secondary use case | Can be used as a low sideboard or display console in dining rooms or entryways |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops - safety requirements and test methods | |
|---|---|---|
| EN 12521:2015 | Furniture - strength, durability and safety for domestic tables | |
| EN 71-3:2019+A1:2021 | Migration of certain elements for furniture used in residential spaces |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to structural and finish quality | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances in wood furniture | |
| GB/T 4893.8-2013 | Test for surface wear resistance of furniture finishes |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to structural and finish quality; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances in wood furniture; 3. GB/T 4893.8-2013: Test for surface wear resistance of furniture finishes; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
