Automatic mm / inch conversion · Core engineering specifications
| Overall central TV console dimensions | 2400 x 450 x 450 mm | |
|---|---|---|
| Left 2-drawer side chest dimensions | 800 x 400 x 750 mm | |
| Right glass display cabinet dimensions | 900 x 400 x 1200 mm | |
| Matching coffee table dimensions | 1300 x 700 x 450 mm | |
| Single TV console drawer internal dimensions | 670 x 380 x 160 mm | |
| Single coffee table drawer internal dimensions | 540 x 380 x 150 mm | |
| Display cabinet glass door clear opening | 320 x 700 mm | |
| Sintered stone top thickness | 12 mm | |
| Carcass panel thickness | 18 mm | |
| Back panel thickness | 9 mm | |
| Drawer slide clearance | 13 mm | |
| Cable management cutout diameter | 60 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| TV console top static load capacity | 80 kg | |
|---|---|---|
| Sintered stone top heat resistance | 1200 °C | |
| Sintered stone surface abrasion resistance | 4 grade | |
| Total set net weight | 220 kg | |
| Residential use warranty period | 2 years | |
| Available color finish options | 2 | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| Top surfaces (all units) | 12mm white snow-pattern sintered stone, polished finish, sealed edges | |
|---|---|---|
| Carcass and drawer fronts | 18mm E0-grade engineered wood, light natural oak veneer, matte finish | |
| Back panels (all units) | 9mm MDF, oak veneer match finish | |
| Display cabinet doors | 5mm clear tempered glass, solid oak wood frame, metal pull handles | |
| Drawer slides | Cold-rolled steel under-mount soft-close slides, zinc-plated finish | |
| Display cabinet hinges | Cold-rolled steel soft-close concealed hinges, nickel-plated finish | |
| Base plinths | Solid rubberwood support framing, oak veneer wrap, floor-level profile | |
| Adjustable shelves (display cabinet) | 18mm engineered wood, oak veneer finish, metal shelf pins | |
| Internal drawer boxes | 12mm poplar solid wood, dovetail joint construction | |
| Edge banding | 1mm PVC oak-matching edge banding, hot-melt applied | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Drawer operation | Push-to-open rebound mechanism, 400mm full extension travel, soft-close dampening | |
|---|---|---|
| Cable management | Dual rear 60mm diameter cable cutouts per TV console section, removable plastic grommets | |
| Display cabinet access | Dual hinged glass doors, 110-degree opening angle, soft-close auto-latch at closed position | |
| Display shelf adjustability | 3 adjustable shelf height positions, 32mm hole spacing, 5kg incremental load rating | |
| Surface protection | Non-slip scratch-resistant sintered stone top, heat-resistant to 1200°C, stain-proof non-porous finish | |
| Floor leveling | Concealed 10mm adjustable leveling feet at plinth corners, 15mm adjustment range | |
| Drawer safety lock | No integrated drawer locks, child-safety magnetic latches available as optional accessory | |
| Ventilation design | 20mm continuous ventilation gap at rear of all enclosed cabinet sections to prevent moisture buildup | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Primary use case | Wall-mounted TV setup in modern residential living rooms, positioned below 85inch flat-screen TVs | |
|---|---|---|
| Matching layout recommendation | Place central TV console centered under TV, side chest to left, display cabinet to right, coffee table centered on seating area rug | |
| Target user group | Urban homeowners seeking minimalist, durable light wood style living room furniture with closed storage | |
| Space size requirement | Minimum 3.8m wide living room wall to accommodate full 4-piece console arrangement without overcrowding | |
| Secondary storage use | Display cabinet stores books, collectibles and tableware; side chest stores media accessories and remote controls | |
| Commercial application suitability | Suitable for hotel suite lounge areas, serviced apartment living spaces and small office reception waiting areas | |
| Surface use guidance | Sintered stone tops support placement of hot drinkware, media devices, table lamps and decorative items without damage |
EU Market Access Requirements* EN Standards
| Formaldehyde emission for wood panels | EN 312:2010 P2 grade for interior furniture use, low emission requirement | |
|---|---|---|
| Furniture mechanical safety for storage units | EN 14749:2016 safety requirements for domestic storage units and kitchen worktops | |
| Tempered glass safety for furniture | EN 12150:2004 safety requirements for thermally toughened soda lime silicate glass |
Standards applicable to China-market projects
| Wood-based panel formaldehyde emission | GB/T 39600E1 grade, ≤0.124mg/m3 emission limit | |
|---|---|---|
| Furniture structural safety for storage units | GB/T 3324 general technical requirements for wooden furniture | |
| Tempered glass for furniture use | GB 15763.2safety tempered glass, impact resistance requirement |
This product must meet the following technical requirements: 1. Wood-based panel formaldehyde emission: GB/T 39600E1 grade, ≤0.124mg/m3 emission limit; 2. Furniture structural safety for storage units: GB/T 3324 general technical requirements for wooden furniture; 3. Tempered glass for furniture use: GB 15763.2safety tempered glass, impact resistance requirement; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
