Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2000 x 400 x 500 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top panel static load capacity | 100 kg | |
|---|---|---|
| Door hinge cycle rating | 80000 open/close cycles | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Tempered glass door impact resistance | 45 kg steel ball drop from 1m height | |
| Anti-tip stability load | 25 kg horizontal force at top edge without overturning | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Top panel | Solid natural oak veneer over high-grade MDF core, 25mm thick, sealed with matte water-based lacquer | |
|---|---|---|
| Carcass frame | Solid oak edge banding + E0-grade engineered oak particleboard core, 18mm thick, matte lacquer finish | |
| End doors | 5mm thick clear tempered safety glass, set in solid oak circular frames, fitted with soft-close concealed hinges | |
| Drawer boxes | 12mm thick E0-grade plywood construction, dovetail joint assembly, solid oak front panels | |
| Drawer slides | Cold-rolled steel full-extension soft-close slides, zinc-plated corrosion-resistant finish | |
| Support legs | Solid natural oak tapered cylindrical legs, 300mm tall, matte lacquer finish, fitted with non-marking plastic floor glides | |
| Back panel | 9mm thick hardboard, oak veneer match finish, pre-cut with cable pass-through openings | |
| Interior shelves | 18mm thick E0-grade engineered oak board, adjustable on metal shelf pins, matte lacquer finish | |
| Door handles | Recessed solid oak finger pulls integrated into door frame, no protruding metal hardware | |
| Finish | Low-VOC matte water-based lacquer, scratch-resistant, light oak natural grain appearance, 0 degree gloss level | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| End cabinet storage | Hinged round glass doors open 110 degrees, fitted with soft-close dampers to prevent slamming, revealing two adjustable interior shelves per compartment | |
|---|---|---|
| Central drawer storage | Two full-extension soft-close drawers extend 350mm outward, providing concealed storage for remote controls, media discs and small accessories | |
| Open AV bay storage | Central open compartment with one fixed shelf, 180mm vertical clearance, sized to hold standard set-top boxes, game consoles and audio receivers | |
| Cable management | Two 60mm diameter cable pass-through ports at rear of open bay, routed through back panel to hide power and AV cords behind the unit | |
| Shelf adjustability | End cabinet shelves adjust in 32mm vertical increments across 5 positions, allowing storage for media items of varying heights | |
| Leveling adjustment | Non-marking leg glides adjust 10mm vertically to compensate for uneven carpet or hard flooring | |
| Ventilation | 10mm continuous gap below open bay shelf and rear panel clearance provides passive air flow for heat-generating AV electronics | |
| Anti-tip protection | Included wall anchor strap secures rear top edge of console to wall studs to prevent forward tipping during top loading | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
EU Market Access Requirements* EN Standards
| EN 312 | 2010 Particleboards - Specifications | |
|---|---|---|
| EN 12521 | 2015 Furniture - Strength, durability and safety for domestic storage furniture | |
| EN 12150-1 | 2015 Glass in building - Thermally toughened soda lime silicate safety glass |
Standards applicable to China-market projects
| GB 15763.2-2005 Safety glazing materials in building - Part 2 | Tempered glass |
|---|
This product must meet the following technical requirements: 1. GB 15763.2-2005 Safety glazing materials in building - Part 2: Tempered glass; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
