PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	2010 × 480 × 560 mm
Leg height	110 mm
Central open cubby compartment size	600 x 400 x 180 mm per cubby
Drawer internal dimensions	630 x 380 x 130 mm per drawer
Top panel thickness	30 mm
Carcass side panel thickness	18 mm
Back panel thickness	9 mm
Shelf thickness for open cubbies	18 mm
Floor clearance under base	110 mm
Rear cable cutout diameter	60 mm
Carcass Panel Thickness	25 mm
Door / Drawer Front Thickness	22 mm
Shelf Thickness	25 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Top surface static load capacity	136 kg
Recommended maximum TV size	85 inch
Drawer slide cycle rating	50000 open/close cycles
Net weight	65 kg
Shelf Distributed Load	30 kg/shelf
Drawer Slide Load / Life	45 kg/pair; 50000 cycles
Hinge Opening Angle / Life	165°; 80000 cycles
Anti-tip Fixing Reference	Products above 1200 mm should use at least 2 wall fixing points
Recommended Procurement Warranty	Carcass 5 years; hardware 3 years; finish 2 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Top panel	Solid rubberwood with matte clear water-based finish
Drawer fronts and carcass panels	Solid rubberwood, flush handleless construction
Legs	Solid rubberwood, angled tapered design
Open cubby shelves	Solid rubberwood, fixed position
Drawer slides	Soft-close full-extension ball bearing steel slides
Back panel	Plywood with ventilated cutouts
Finish coating	Low-VOC matte water-based lacquer
Edge Band Thickness	2 mm
Primary Connector Specification	Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints
Reference Finish / Color Count	Recommended 6finish options

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Drawer operation	Push-to-open soft-close mechanism, no external handles
Cable management	Three rear 60mm cutouts aligned to open cubbies
Central storage layout	Two stacked open cubbies for AV equipment access
Side storage layout	Four stacked drawers (two left, two right) for concealed storage
Ventilation	Open cubby rear panels include ventilation slots
Assembly requirement	Leg attachment only, carcass pre-assembled
Cable / Vent Opening Reference	80 mm diameter; recommend 4rear cable/vent openings

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	2100× 700× 350 mm/carton according to carcass split
Reference Packaged Gross Weight	100 kg/set in 3 cartons
Reference Packaging Volume	0.65 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Primary use space	Residential living room media wall, positioned below wall-mounted or standing TV
Matching furniture set	Pairs with matching tall glass-front side display cabinets for coordinated media wall
Secondary use case	Low profile sideboard for open-plan living/dining areas, storing tableware and linens
Target user	Households preferring Scandinavian/Nordic minimalist natural wood interiors
Recommended placement	Against flat wall with 100mm clearance behind for cable routing and ventilation

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 14749:2016	Domestic and kitchen storage units and worktops - safety requirements and test methods
EN 13722:2004	Furniture - strength and durability of storage furniture for non-domestic use

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable for structural integrityAcceptance
GB 18584-2001	Indoor decorating and refurbishing materials - limit of harmful substances of wood based furniture
GB/T 4893.8-2013	Test method for surface abrasion resistance of furniture finishes

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural integrityAcceptance;
2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances of wood based furniture;
3. GB/T 4893.8-2013: Test method for surface abrasion resistance of furniture finishes;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · TVC-NOK-2010

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · TVC-NOK-2010

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · TVC-NOK-2010Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Nordic Light Oak Solid Wood TV Media Console (model TVC-NOK-2010) is an unbranded storage piece rooted in Scandinavian minimalist design, defined by clean, unadorned lines and warm natural wood tones. Its low-profile rectangular form features angled tapered solid wood legs elevating the main carcass, with a flush, handleless front facade that creates a seamless, uncluttered visual profile. The central section houses two stacked open cubbies, flanked symmetrically by two stacked drawers on the left and two on the right, creating a balanced, symmetrical layout suited to curated interior schemes.
Constructed primarily from solid light natural rubberwood, the console features a 30mm thick top panel finished with a low-VOC matte clear water-based lacquer that highlights the wood’s natural grain. Carcass side panels measure 18mm thick, open cubby shelves are 18mm thick fixed solid rubberwood, and the back panel is plywood fitted with ventilated cutouts. Drawer fronts use solid rubberwood for a flush finish, supported by soft-close full-extension ball bearing steel slides, and angled tapered legs are cut from solid rubberwood. Major joints use M6-M8 cam/bolt fittings with at least two fixing points per connection, and all visible edges feature 2mm edge banding for a polished, durable finish.
Functional design supports streamlined media use: the push-to-open soft-close drawer mechanism eliminates protruding hardware, with each drawer rated for 45kg load capacity and 50,000 open-close cycles, while hinges support 165° opening over 80,000 cycles. The central open cubbies include aligned rear cable cutouts and ventilation slots, with three 60mm rear openings to route cords for AV equipment, and each fixed shelf supports 30kg distributed load. The top surface holds up to 136kg of static weight, accommodating TVs up to 85 inches, and the carcass arrives pre-assembled, requiring only leg attachment for setup. Assembly takes an 40 minutes per unit.
This console is designed for primary placement on residential living room media walls, positioned below wall-mounted or standing TVs with 100mm clearance behind the unit for cable routing and airflow. It pairs seamlessly with matching tall glass-front side display cabinets for a coordinated media wall look, and works as a low-profile sideboard in open-plan living and dining areas to store tableware and linens, serving households that favor Nordic minimalist natural wood interiors.
Procurement teams should note the unit ships across multiple cartons with a total packaged gross weight of 100kg and total packaging volume of 0.65m³ per set. For space planning, the fully assembled unit measures 2010mm wide, 480mm deep, and 560mm tall, with 110mm leg height. Internal storage includes 600 x 400 x 180mm central cubbies and 630 x 380 x 130mm per drawer, so teams should confirm these dimensions align with intended AV equipment or stored items prior to ordering.

Nordic Light Oak Solid Wood TV Media Console with 4 Drawers and Central Open Cubbies Specifications
