Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1600 × 400 × 470 mm | |
|---|---|---|
| TV stand floor clearance | 150 mm | |
| TV stand drawer internal dimensions | 590 x 300 x 80 mm | |
| TV stand open cubby internal dimensions | 300 x 350 x 200 mm | |
| Coffee table drawer internal dimensions | 400 x 500 x 100 mm | |
| Coffee table open shelf internal dimensions | 350 x 500 x 200 mm | |
| Tabletop thickness | 25 mm | |
| Carcass panel thickness | 18 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| TV stand top static load capacity | 113 kg | |
|---|---|---|
| Recommended maximum TV size | 75 in | |
| Drawer slide cycle rating | 50000 cycles | |
| Set total net weight | 47 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| TV/coffee tabletops | 18mm engineered wood substrate with light oak matte veneer finish | |
|---|---|---|
| Accent side/divider panels | 18mm MDF with matte white powder-coated finish | |
| Support legs | Solid rubber wood tapered angled legs with natural clear matte finish | |
| Lower apron trim | Woven rattan-style synthetic wicker trim along bottom edge | |
| Drawer fronts | Engineered wood with matching oak veneer, fitted with gold-toned metal knobs | |
| Drawer slides | Cold-rolled steel side-mount drawer slides | |
| Back panels | 3mm hardboard with pre-drilled cable management openings | |
| Internal shelf surfaces | Matching oak-effect laminated engineered wood | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| TV stand storage layout | Two soft-closing drawers paired with two open display cubbies for media accessories | |
|---|---|---|
| Coffee table storage layout | One right-side storage drawer paired with one left open display shelf | |
| TV cable management | Two 60mm diameter rear cutouts for media device power and HDMI routing | |
| Drawer operation | Side-mount slides with 3/4 extension for easy access to stored items | |
| Floor protection | Felt floor glides fitted to leg bases to prevent hard floor scratching | |
| Assembly requirement | Flat-pack assembly with cam-lock hardware for home installation | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Small apartment living room | Compact footprint fits 30sqm urban living spaces against main feature walls | |
|---|---|---|
| Scandinavian/boho interior schemes | Two-tone oak and white finish with rattan trim complements neutral natural-toned decor | |
| TV sizes 55 to 75 inches | 1600mm wide top provides stable base for large flat-screen televisions | |
| Open-plan lounge areas | Low profile maintains sight lines across open concept living and dining zones | |
| Residential rental properties | Durable matte finish hides minor wear, simple assembly supports tenant installation |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Strength, durability and safety for non-domestic seating and storage furniture, applicable for structural testing | |
|---|---|---|
| EN 12521:2015 | Safety requirements for residential tables, applicable to coffee table edge and load performance |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural stability | |
|---|---|---|
| GB 18584-2001 | Formaldehyde emission limit for interior decoration wooden furniture, recommended acceptance threshold ≤1.5mg/L |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural stability; 2. GB 18584-2001: Formaldehyde emission limit for interior decoration wooden furniture, recommended acceptance threshold ≤1.5mg/L; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
