Automatic mm / inch conversion · Core engineering specifications
| Overall extended dimensions | 2800 x 400 x 460 mm | |
|---|---|---|
| Minimum retracted length | 1500 mm | |
| Leg height | 100 mm | |
| Left cabinet internal dimensions | 400 x 340 x 300 mm | |
| Central open shelf dimensions | 1000 x 340 x 200 mm | |
| Single right drawer internal dimensions | 550 x 340 x 120 mm | |
| Top panel thickness | 25 mm | |
| Shelf and side panel thickness | 16 mm | |
| Cable management cutout diameter | 60 mm | |
| Floor clearance under unit | 100 mm | |
| Corner edge radius | 10 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top surface static load capacity | 90 kg | |
|---|---|---|
| Maximum supported TV size | 100 inch | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Net product weight | 48 kg | |
| Available color options | 2 | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| Top and outer frame | 25 mm E1 grade engineered wood with light beech wood veneer, matte finish | |
|---|---|---|
| Door and drawer fronts | 18mm MDF panel with matte white scratch-resistant laminate finish | |
| Support legs | Solid rubberwood tapered cylindrical legs, clear matte lacquer coating | |
| Back panel | 3mm hardboard with pre-cut cable openings | |
| Internal cabinet shelf | 16mm E1 grade engineered wood, matching wood veneer finish | |
| Drawer box construction | 12mm plywood drawer sides with polished metal slide hardware | |
| Cabinet door hardware | Concealed soft-close 90-degree opening hinges | |
| Telescopic extension hardware | Cold-rolled steel ball-bearing slide rails, powder-coated black finish | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Telescopic length adjustment | Manual left-segment slide adjusts length from 1500mm to 2800mm, with internal support leg for stability | |
|---|---|---|
| Left cabinet storage | Single hinged door with recessed pull opens 90 degrees to reveal fixed shelf for media component storage | |
| Right drawer storage | Two equal-width push-to-open drawers open without external handles, for remote and accessory storage | |
| Central open shelf | Fixed open lower bay for set-top boxes, routers, or display items, unobstructed access | |
| Cable management | Rear cutouts allow wiring pass-through for TV, media players, and power cords | |
| Anti-tip safety | Included wall anchor hardware secures unit to wall to prevent tipping with heavy top loads | |
| Surface protection | Matte finish resists water rings and minor scratches from decor and media devices | |
| Floor protection | Felt pads pre-installed on leg bases to prevent scratching wood and tile flooring | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Living room TV placement | Suits placement against walls in small to medium apartments, supporting up to 100-inch flatscreen TVs | |
|---|---|---|
| Open-plan living space use | Low 460mm height does not obstruct sightlines in open concept lounge and dining areas | |
| Combined storage and display | Mix of closed storage and open shelving suits displaying decor while hiding media accessories | |
| Scandinavian interior schemes | Two-tone light wood and white finish matches Nordic, minimalist, and modern casual decor styles | |
| Rental property furnishing | Adjustable length fits variable wall sizes in rental units, easy to disassemble and move |
EU Market Access Requirements* EN Standards
| EN 312:2010 | Particleboard performance specification, applicable for verifying structural panel suitability | |
|---|---|---|
| EN 14749:2016 | Domestic and kitchen storage furniture safety requirements, applicable for stability and strength testing | |
| EN 12521:2015 | Domestic furniture strength and durability standard for seating-adjacent storage units |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural quality inspection | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required E1 grade emission ≤0.124mg/m³ for indoor use | |
| GB/T 4893.8-2013 | Surface furniture wear resistance test standard, applicable for laminate finish durability checks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural quality inspection; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required E1 grade emission ≤0.124mg/m³ for indoor use; 3. GB/T 4893.8-2013: Surface furniture wear resistance test standard, applicable for laminate finish durability checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
