Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (fully extended) | 2500 x 480 x 500 mm | |
|---|---|---|
| Left stacked drawer unit width | 700 mm | |
| Center open media cubby dimensions | 500 x 400 x 250 mm | |
| Right side-by-side drawer unit width | 1300 mm | |
| Leg height | 100 mm | |
| Drawer internal usable dimensions | 480 x 380 x 120 mm | |
| Top surface panel thickness | 25 mm | |
| Carcass side panel thickness | 18 mm | |
| Back panel cable cutout diameter | 60 mm | |
| Under-cabinet floor clearance | 100 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Total top surface static load capacity | 80 kg | |
|---|---|---|
| Total product net weight | 75 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Recommended maximum TV size | 75 inch | |
| Surface finish abrasion resistance | 1000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main structural frame | Solid imported rubberwood | |
|---|---|---|
| Top surface | Solid rubberwood with walnut-toned eco-lacquer finish | |
| Drawer panels | Solid rubberwood with recessed curved wood pulls | |
| Support legs | Solid rubberwood, squared short profile | |
| Back panel | Multi-layer engineered wood board | |
| Drawer slides | Cold-rolled steel with silent soft-close coating | |
| Internal shelf base | Solid rubberwood edge-banded engineered wood | |
| Surface finish | Low-VOC water-based polyurethane lacquer | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Telescoping length adjustment | Sliding split top extends to 2500mm, retracts to 1500mm to fit variable wall lengths | |
|---|---|---|
| Drawer storage configuration | 4 total drawers: 2 stacked left, 2 side-by-side right for media accessories | |
| Open media storage cubby | Central open slot for set-top boxes, books, or decorative items without door obstruction | |
| Cable management system | Rear 60mm cutouts route power and AV cables from devices to wall outlets | |
| Floor-standing installation | Fixed position on short wood legs, no wall mounting required for standard use | |
| Smooth drawer operation | Side-mounted steel slides enable full extension without binding | |
| Tipover resistance | Wide low center of gravity, compatible with optional wall anchor for child safety | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential living room placement | Positioned against a wall below wall-mounted or stand-supported flat screen TVs | |
|---|---|---|
| Apartment and small home use | Retractable length fits compact 1.5m to 2.5m wall spaces for flexible layout | |
| Mixed media and decorative storage | Combines closed concealed storage for clutter with open display for decor and media devices | |
| New Chinese style interior matching | Walnut solid wood finish complements traditional and modern Chinese home decor schemes | |
| Low-height media viewing alignment | 500mm height positions TV center at seated eye level for comfortable viewing |
EU Market Access Requirements* EN Standards
| EN 312:2010 | Particleboard specifications, applicable for engineered wood component performance verification | |
|---|---|---|
| EN 12521:2015 | Furniture - strength, durability and safety requirements for domestic storage furniture | |
| EN 71-3:2019+A1:2021 | Safety of toys - migration of certain elements, applicable for surface finish heavy metal limits |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and finish qualityAcceptance inspection | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture | |
| GB/T 4897.3-2017 | Particleboard for furniture use, applicable if engineered wood panels are used in construction |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and finish qualityAcceptance inspection; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture; 3. GB/T 4897.3-2017: Particleboard for furniture use, applicable if engineered wood panels are used in construction; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
