Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 400 x 450 mm | |
|---|---|---|
| Leg height | 150 mm | |
| Central slatted door compartment width | 600 mm | |
| Side drawer bank width | 600 mm per bank | |
| Individual drawer front height | 120 mm | |
| Top panel thickness | 25 mm | |
| Carcass side panel thickness | 18 mm | |
| Back panel thickness | 5 mm | |
| Internal shelf depth in central cabinet | 360 mm | |
| Clearance under console base | 120 mm | |
| Cable management opening diameter | 60 mm | |
| Slat gap width on central door | 12 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Total product weight | 50 kg | |
|---|---|---|
| Top surface static load capacity | 75 kg | |
| Maximum supported TV screen size | 80 inch | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Surface scratch resistance rating | 2000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| Top panel | 18mm MDF core with walnut wood grain melamine veneer, rounded edge profile | |
|---|---|---|
| Carcass panels | 18mm particleboard with matching walnut grain laminate finish | |
| Back panel | 5mm hardboard with pre-cut cable management ports | |
| Tapered splayed legs | Solid rubberwood with walnut stain finish, angled 15 degrees outward | |
| Recessed half-moon handles | Integrated solid wood pulls matching carcass finish, flush-mounted | |
| Central slatted door | Engineered wood frame with vertical solid wood slats forming ventilation grille | |
| Drawer slides | Full-extension cold-rolled steel side-mount slides | |
| Door hinges | Concealed soft-close steel hinges with 110-degree opening angle | |
| Internal adjustable shelf | 15mm engineered wood with walnut edge banding, 3-position height adjustment | |
| Foot pads | Non-marking PE pads on leg bases to protect floor surfaces | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Side storage configuration | Two double-drawer banks (four total drawers) for concealed media accessory storage | |
|---|---|---|
| Central compartment access | Single slatted-front hinged door enclosing adjustable shelf for AV equipment | |
| Ventilation feature | Vertical slat gaps on central door provide passive airflow for heat-generating electronics | |
| Cable management | Rear pre-drilled 60mm ports route power and AV cables through back panel | |
| Shelf adjustability | Central cabinet shelf adjusts to 3 height positions to accommodate tall AV components | |
| Drawer operation | Full-extension slides allow full access to drawer interior for media and accessory retrieval | |
| Door operation | Soft-close hinges prevent slamming and reduce noise in living room spaces | |
| Floor protection | Non-slip non-marking foot pads prevent scuffs on hard flooring surfaces | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Primary use case | Living room wall placement under flat-screen televisions up to 80 inches for media equipment storage | |
|---|---|---|
| Secondary storage use | Holds media accessories, remote controls, books and small decor items on top and in drawers | |
| Suitable interior styles | Mid-century modern, Scandinavian, retro, contemporary walnut-toned living rooms | |
| Recommended floor surfaces | Hardwood, laminate, tile, or low-pile carpeted residential floors | |
| Placement clearance requirement | 100 mm rear clearance from wall to accommodate cable connections and airflow | |
| Target user group | Residential homeowners seeking compact, ventilated media storage with classic mid-century styling |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops safety requirements, applicable for structural stability | |
|---|---|---|
| EN 12521:2015 | Domestic furniture strength, durability and safety requirements for seating-adjacent storage | |
| EN 717-1:2004 | Wood-based panels formaldehyde emission determination, applicable for E1 grade material verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and finish quality acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture, applicable for formaldehyde emission verification | |
| GB/T 4893.4-2013 | Furniture surface test for abrasion resistance, applicable for melamine top finish durability | |
| GB/T 10357.5-2011 | Furniture mechanical test for storage unit strength and stability, applicable for load and tip-over verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and finish quality acceptance; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture, applicable for formaldehyde emission verification; 3. GB/T 4893.4-2013: Furniture surface test for abrasion resistance, applicable for melamine top finish durability; 4. GB/T 10357.5-2011: Furniture mechanical test for storage unit strength and stability, applicable for load and tip-over verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
