Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 400 x 450 mm | |
|---|---|---|
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Net product weight | 42 kg | |
|---|---|---|
| Top surface static load capacity | 50 kg | |
| Recommended maximum TV size | 75 inch | |
| Drawer slide cycle rating | 30000 open/close cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main cabinet frame | Solid rubberwood with natural clear matte finish | |
|---|---|---|
| Drawer front panels | 18mm thick MDF with matte white PU paint finish | |
| Support legs | Solid rubberwood tapered cylindrical legs | |
| Drawer handles | Solid rubberwood horizontal/vertical pulls | |
| Top surface | 25mm thick solid rubberwood panel | |
| Drawer internal box | 12mm thick plywood with smooth melamine lining | |
| Back panel | 5mm thick MDF with pre-drilled cable management cutouts | |
| Drawer slides | Cold-rolled steel side-mount 3/4 extension slides | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | 4 equal-width soft-close drawers across full cabinet width | |
|---|---|---|
| Cable management | Pre-cut openings on back panel for AV and power cord routing | |
| Floor protection | Non-slip felt pads pre-installed on leg bases | |
| Assembly requirement | Knock-down assembly with legs attached via included hex hardware | |
| Drawer operation | Pull-handle actuation with 300mm extension depth | |
| Surface use | Flat, level top surface suitable for TV placement and decor display | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential living room | Placed against a wall as primary media storage under wall-mounted or stand-mounted TVs | |
|---|---|---|
| Small apartment living spaces | Compact 400mm depth fits narrow rooms without protruding into walkways | |
| Bedroom media setup | Used at foot of bed or bedroom wall for smaller TV and linen storage | |
| Scandinavian/Japandi interior schemes | Two-tone natural wood and white finish matches minimalist Nordic design palettes |
EU Market Access Requirements* EN Standards
| Surface durability | EN 15187:2006 | |
|---|---|---|
| Structural safety | EN 14749:2016 |
Standards applicable to China-market projects
| Formaldehyde emission | GB/T 18580E1 grade | |
|---|---|---|
| Mechanical stability | GB/T 10357.1 |
This product must meet the following technical requirements: 1. Formaldehyde emission: GB/T 18580E1 grade; 2. Mechanical stability: GB/T 10357.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
