Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 400 x 1800 mm | |
|---|---|---|
| Upper glass door section height | 1250 mm | |
| Lower solid door compartment height | 500 mm | |
| Single glass door width | 430 mm | |
| Single lower solid door width | 430 mm | |
| Adjustable shelf thickness | 20 mm | |
| Shelf vertical adjustment increment | 32 mm | |
| Internal clear shelf depth | 370 mm | |
| Handle length | 100 mm | |
| Frame material thickness | 0.8 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Net weight | 75 kg | |
|---|---|---|
| Per-shelf static load capacity | 50 kg | |
| Upper storage compartment capacity | 420 L | |
| Lower storage compartment capacity | 160 L | |
| Recommended maximum door opening angle | 110 degrees | |
| Cam lock cycle durability | 10000 cycles | |
| Shelf adjustment count positions | 12 positions per shelf | |
| Product warranty | 3 years | |
| Maximum door opening angle | 110 degrees | |
| Shelf adjustment position count | 12 positions per shelf |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main cabinet body | 0.8mm thick 304 grade brushed stainless steel sheet | |
|---|---|---|
| Upper door panels | 5mm thick frosted semi-transparent tempered glass | |
| Lower door panels | 0.8mm thick brushed stainless steel solid sheet | |
| Adjustable shelves | 0.8mm thick stainless steel sheet with folded reinforced edges | |
| Internal shelf supports | Galvanized steel punch rails | |
| Door handles | Brushed stainless steel recessed pull handles | |
| Locking mechanisms | Zinc alloy keyed cam locks | |
| Door hinges | Stainless steel concealed butt hinges | |
| Back panel | 0.6mm thick stainless steel sheet | |
| Surface finish | Uniform brushed #4 finish on all stainless steel surfaces | |
| Anti-tip hardware | 2 zinc-plated steel wall anchor brackets, included with installation screws | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Upper compartment locking | Keyed central lock secures both upper glass doors simultaneously | |
|---|---|---|
| Lower compartment locking | Keyed lock on right lower door secures both lower solid doors | |
| Shelf height adjustment | Tool-free adjustable shelf positioning via slotted support rails on 32mm increments | |
| Door operation | Double hinged doors swing open outward to provide full access to cabinet interior | |
| Upper glass door visibility | Frosted glass panels obscure stored item details while allowing light transmission and general contents visibility | |
| Lower enclosed storage | Solid metal lower doors fully conceal stored items for dust protection and visual privacy | |
| Recessed handle design | Flush recessed pulls eliminate protruding hardware to reduce impact risk in high-traffic corridors | |
| Leveling adjustment | Pre-drilled base accepts optional adjustable leveling feet for uneven floor installation | |
| Lock cylinder diameter | 20 mm | |
| Anti-tip protection | 2 included wall anchor brackets fasten cabinet top rear to wall structure, preventing forward tipping when fully loaded or doors are fully open | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Number of packages | 1 unit | |
|---|---|---|
| Packaging carton dimensions | 980 x 480 x 1880 mm | |
| Gross shipping weight | 90 kg | |
| Packaging volume CBM | 0.89 CBM | |
| Assembly time | 10 minutes | |
| 20ft GP container loading quantity | 24 units | |
| 40ft HQ container loading quantity | 60 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split |
Recommended spaces / users / usage modes
| Office document storage | Suitable for corporate offices to store files, folders and reference materials, with glass doors for quick visual location of documents | |
|---|---|---|
| Medical and cleanroom storage | Stainless steel construction is suitable for clinic, laboratory and cleanroom environments requiring easy disinfection and corrosion resistance | |
| Laboratory equipment storage | Adjustable shelves accommodate lab supplies, glassware and equipment of varying heights, locked lower section secures hazardous or controlled materials | |
| Breakroom and pantry storage | Can be used in staff break areas to store tableware, supplies and dry goods, with stainless steel surface resistant to food and liquid spills | |
| Educational facility storage | Suitable for schools and training centers to store teaching materials, supplies and administrative records, durable construction withstands frequent daily use | |
| Workshop tool and supply storage | Can be deployed in industrial workshops to store hand tools, maintenance parts and supplies, resistant to oil and common workshop contaminants | |
| Medical and clinic storage | Stainless steel construction is suitable for clinic, treatment room and cleanroom environments requiring easy disinfection and corrosion resistance to cleaning agents | |
| Workshop supply storage | Can be deployed in industrial workshops to store hand tools, maintenance parts and PPE supplies, resistant to oil and common workshop contaminants |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Applicable European standard for office storage furniture, specifies safety and strength requirements for standing storage cabinets | |
|---|---|---|
| EN 14434:2004 | Applicable European standard for storage furniture locks, specifies performance and durability requirements for locking mechanisms |
Standards applicable to China-market projects
| GB/T 13668-2015 | Applicable standard for steel office storage cabinets, specifies dimensional tolerance, structural strength and coating performance requirements for procurement acceptance | |
|---|---|---|
| GB/T 24821-2009 | Applicable standard for office furniture lock performance, specifies key operation, durability and security requirements for cabinet locks | |
| GB 15763.2-2005 | Applicable standards and test results require confirmation |
This product must meet the following technical requirements: 1. GB/T 13668-2015: Applicable standard for steel office storage cabinets, specifies dimensional tolerance, structural strength and coating performance requirements for procurement acceptance; 2. GB/T 24821-2009: Applicable standard for office furniture lock performance, specifies key operation, durability and security requirements for cabinet locks; 3. GB 15763.2-2005: Applicable standards and test results require confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
