Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 400 x 1850 mm | |
|---|---|---|
| Single door panel dimensions | 440 x 1780 mm | |
| Internal storage clear height | 1760 mm | |
| Adjustable shelf quantity | 4 pcs | |
| Single shelf depth | 380 mm | |
| Door frame edge width | 30 mm | |
| Wall clearance gap at rear | 20 mm | |
| Single shelf width | 860 mm | |
| Back panel thickness | 0.6 mm | |
| Edge band thickness | 1 mm | |
| Internal compartment height range | 100 mm | |
| Plinth height | 50 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Net weight range | 58 kg | |
|---|---|---|
| Per shelf static load capacity | 50 kg | |
| Door hinge cycle rating | 50000 open/close cycles | |
| Lock mechanism key differ quantity | 200 combinations | |
| Powder coating abrasion resistance | 1000 cycles | |
| Usable internal volume | 0.58 cbm | |
| Anti-tip load resistance | 150 N | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main cabinet body panels | 0.8mm thick cold-rolled steel | |
|---|---|---|
| Door panels | 0.8mm thick cold-rolled steel with folded reinforced edges | |
| Adjustable shelves | 0.9mm thick cold-rolled steel with front/back bends for rigidity | |
| Surface finish | Epoxy polyester powder coating, light grey RAL 7035 | |
| Hinges | Zinc-plated steel internal hinges, 3 per door | |
| Lock assembly | Zinc alloy recessed 3-point locking mechanism with 2 keys | |
| Shelf support clips | Zinc-plated steel adjustable clips, 4 per shelf | |
| Base plinth | 1.0mm thick cold-rolled steel welded construction | |
| Back panel | 0.6mm thick cold-rolled steel, spot-welded to carcass frame for enclosure | |
| Anti-tip hardware | Included 2 steel wall anchor brackets with matching concrete/wood screws | |
| Internal uprights | 1.0mm thick cold-rolled steel vertical rails with 32mm spaced punched holes for shelf adjustment | |
| Door edge seals | 0.5mm thick PVC foam gaskets along door inner perimeter to reduce dust ingress |
Adjustment / rotation / tilt / mobility / storage features
| Locking system | Recessed handle operates 3-point steel latching at top, middle and bottom of doors, includes 2 numbered keys | |
|---|---|---|
| Shelf adjustment | Shelves adjust in 32mm vertical increments via pre-punched holes on internal uprights | |
| Door operation | Hinged doors swing outward 110 degrees to provide full access to internal storage, no protruding external hardware | |
| Assembly structure | Knock-down flat-pack construction with bolt-together connections for on-site assembly | |
| Anti-tip provision | Pre-drilled holes on rear panel for wall anchoring to prevent tipping when loaded or doors are fully open | |
| Storage compartment configuration | 4 adjustable shelves create 5 separate storage compartments when fully assembled | |
| Handle/lock assembly size | 60 x 90 mm | |
| Floor leveling | 4 adjustable 12mm diameter PVC glides at base corners, 15mm vertical adjustment range to compensate for uneven floor surfaces | |
| Dust protection | Full-perimeter foam door seals close 2mm gap between door and frame, reduces airborne dust entry into internal storage by 90% in typical office environments | |
| Door latching alignment | Spring-loaded latch pins engage with frame strike plates with 3mm tolerance to ensure secure closure even with minor panel alignment variation | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Number of packages | 1 pc | |
|---|---|---|
| Packed carton dimensions | 950 x 450 x 120 mm | |
| Gross weight per package | 62 kg | |
| CBM per unit | 0.051 cbm | |
| assembly time | 35 minutes | |
| 20ft GP container loading quantity | 270 pcs | |
| 40ft HQ container loading quantity | 650 pcs | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split |
Recommended spaces / users / usage modes
| General office storage | Suitable for storing files, office supplies, documents and equipment in open plan offices, administrative areas and back-of-house zones, lockable doors secure sensitive materials | |
|---|---|---|
| Industrial workshop storage | Suitable for workshop, warehouse and facility storage of tools, parts and personal protective equipment, steel construction resists impact and wear | |
| Educational facility use | Suitable for school staff rooms, classroom storage and administrative offices to store books, materials and records, adjustable shelves accommodate different item sizes | |
| Healthcare facility storage | Suitable for clinic and hospital administrative areas to store supplies, forms and non-clinical materials, smooth powder coat finish supports regular disinfection cleaning | |
| Utility and janitorial storage | Suitable for building utility rooms to store cleaning supplies, maintenance tools and spare parts, lockable doors restrict access to hazardous materials | |
| General open-plan office storage | Suitable for storing A4/F4 filing boxes, office supplies, bound documents and small equipment in open plan offices, administrative areas and back-of-house zones, lockable doors secure sensitive personnel and financial materials | |
| Retail back-of-house storage | Suitable for retail store stock rooms and office areas to store inventory supplies, packaging materials and operational documents, 50kg per shelf load rating supports stacked retail inventory without deformation |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Applicable European standard for office storage furniture safety requirements, specifies structural stability and strength criteria | |
|---|---|---|
| EN 16121:2013 | Applicable standard for non-domestic storage furniture, defines durability, load capacity and safety performance requirements |
Standards applicable to China-market projects
| GB/T 3327-2016 | Applicable standard for metal office storage furniture, specifies dimensional tolerance, structural strength and finish requirements for procurement acceptance | |
|---|---|---|
| GB/T 1732-1993 | Applicable standard for paint film impact resistance testing, validates powder coating durability on steel cabinet surfaces | |
| GB 18584-2001 | Applicable standard for indoor furniture environmental testing, limits formaldehyde and heavy metal content for indoor office use | |
| GB/T 4893.8-2013 | Applicable standard for furniture surface abrasion resistance testing, validates powder coat wear performance for high-traffic use |
This product must meet the following technical requirements: 1. GB/T 3327-2016: Applicable standard for metal office storage furniture, specifies dimensional tolerance, structural strength and finish requirements for procurement acceptance; 2. GB/T 1732-1993: Applicable standard for paint film impact resistance testing, validates powder coating durability on steel cabinet surfaces; 3. GB 18584-2001: Applicable standard for indoor furniture environmental testing, limits formaldehyde and heavy metal content for indoor office use; 4. GB/T 4893.8-2013: Applicable standard for furniture surface abrasion resistance testing, validates powder coat wear performance for high-traffic use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
