MC-DD900-GY

Code:CJDXC8V1
Request supplier quotes

Light Gray Double-Door Wall-Mounted/Desktop Metal Storage Cabinet Key Specifications 2026-08-05 17:15

Popularity: 9
Parameter Correction History (Public)
SubmittedFieldOriginal修改后参数Note / Status
No parameter correction records exist. If you spot inaccurate data, click the flag icon at the end of the corresponding row to submit feedback.

MC-DD900-GY

1 active supplier(s) >>
CNYUANTONGSupplierYear 1Company Profile
Product supplierLight Gray Double-Door Wall-Mounted/Desktop Metal Storage Cabinet,sheet metal
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Overall dimensions900 x 400 x 850 mm
Single door panel dimensions435 x 780 mm
Door frame border width30 mm
Internal shelf count1
Shelf adjustment hole spacing32 mm
Handle length90 mm
Internal net width860 mm
Internal net depth380 mm
Internal total net height790 mm
Carcass Panel Thickness25 mm
Back Panel Thickness9 mm
Door / Drawer Front Thickness22 mm
Shelf Thickness25 mm
PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Assembled product net weight28 kg
Uniform distributed shelf load capacity50 kg
Door hinge cycle rating50000 open/close cycles
Lock mechanism cycle rating10000 lock/unlock cycles
Coating scratch resistance2H pencil hardness
Anti-tip load resistance50 kg horizontal force
Shelf Distributed Load30 kg/shelf
Drawer Slide Load / Life45 kg/pair; 50000 cycles
Hinge Opening Angle / Life165°; 80000 cycles
Anti-tip Fixing ReferenceProducts above 1200 mm should use at least 2 wall fixing points
PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Main body panel construction0.8mm thick cold-rolled steel sheet
Exterior finishLight gray epoxy polyester powder coating
Door hingesZinc-plated steel concealed hinges
Lock mechanismZinc alloy keyed cam lock with 2 supplied keys
Door handlesBrushed nickel-plated zinc alloy recessed pull handles
Adjustable shelves0.8mm thick cold-rolled steel with folded reinforced edges
Wall mounting brackets1.5mm thick galvanized steel brackets
Surface coating thickness60 um
Rear back panel0.5mm thick cold-rolled steel sheet, spot-welded to carcass frame
Wall mounting hardware1.5mm thick galvanized steel brackets with M8 expansion bolts for concrete walls
Internal shelf support clipsZinc-plated steel shelf clips, 4 per shelf
Base constructionFolded cold-rolled steel integrated base with 10mm floor clearance
PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Door operationTwo side-hinged solid steel doors that open 110 degrees outward to provide full access to internal storage space
Locking functionKeyed cam lock on right door that engages both doors simultaneously to secure all contents, supplied with 2 identical keys
Shelf adjustability1 removable, height-adjustable steel shelf that can be repositioned at 32mm increments along vertical frame holes to accommodate items of varying heights
Mounting versatilitySuitable for both desktop placement on work surfaces and wall-mounted installation via 4 pre-drilled rear mounting holes
Door alignmentAdjustable hinge screws to compensate for installation unevenness and maintain flush door alignment
Edge protectionFolded and hemmed panel edges on all exposed steel parts to eliminate sharp edges for user safety
Lock cylinder diameter20 mm
Anti-tip protection2 included anti-tip wall anchors to secure the cabinet to wall studs and prevent forward tipping when doors are fully open and loaded
Surface cleanabilitySealed powder coated surface that is resistant to common office cleaners, oil, and dust, with no porous crevices for dirt accumulation
Cable / Vent Opening ReferenceIf fitted, 80 mm diameter
PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Number of shipping packages1
Shipping carton dimensions950 x 450 x 900 mm
Gross shipping weight32 kg
Assembly time30 minutes
20ft GP container loading quantity175 units
40ft HQ container loading quantity430 units
Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Package Dimensions2100× 700× 350 mm/carton according to carcass split
Reference Packaged Gross Weight100 kg/set in 3 cartons
PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Office workspace storageSuitable for placement under desks or on credenzas in open offices or private workstations to store documents, office supplies and small equipment
Workshop and utility storageSuitable for mounting on workshop walls to store tools, parts and maintenance supplies, with durable steel construction resisting wear and impact
Healthcare and laboratory storageSuitable for medical offices or lab stations to store PPE, testing supplies and sterile items, with non-porous surface that supports regular disinfection
Residential home office useSuitable for home study or craft rooms to store files, craft supplies and household essentials, with neutral light gray finish matching most interior decor
Retail back-of-house storageSuitable for retail stock rooms to store small inventory items, receipts and store supplies, with durable construction supporting frequent daily access
Educational facility storageSuitable for classroom or school administration areas to store student records, art supplies and classroom materials, with scratch-resistant finish standing up to frequent student and staff use
STANDARD S1

EU EN Standards

European market access and chemical requirements

EN 14073-2:2004Applicable standard for office storage furniture safety requirements, covering stability, strength and durability for commercial use
EN 1022:2005Applicable standard for furniture stability testing, required to verify cabinet does not tip when doors are fully opened with load
EN 15187:2006Applicable standard for furniture surface resistance to cold liquids, required to verify finish resistance to common cleaning agents and spills
STANDARD S2

North America ANSI/BIFMA Standards

US and Canada office-furniture standards

No standards data is available for this market.
STANDARD S3

China GB Standards

Standards applicable to China-market projects

GB/T 3327-2016Applicable standard for metal office furniture general technical requirements, covering dimensional tolerance, structural strength and coating performance for acceptance
GB/T 1732-1993Applicable standard for coating impact resistance testing, required to verify 50cm impact resistance of powder coated surfaces
GB/T 1768-2006Applicable standard for coating abrasion resistance testing, required to verify 1000-cycle abrasion resistance for high-use cabinet surfaces
Standard Tender Description
This product must meet the following technical requirements:
1. GB/T 3327-2016: Applicable standard for metal office furniture general technical requirements, covering dimensional tolerance, structural strength and coating performance for acceptance;
2. GB/T 1732-1993: Applicable standard for coating impact resistance testing, required to verify 50cm impact resistance of powder coated surfaces;
3. GB/T 1768-2006: Applicable standard for coating abrasion resistance testing, required to verify 1000-cycle abrasion resistance for high-use cabinet surfaces;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · MC-DD900-GY

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · MC-DD900-GY

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · MC-DD900-GYOpen Export Tool

Quick Actions

Post Inquiry

Product Overview & Construction Details

The Light Gray Double-Door Wall-Mounted/Desktop Metal Storage Cabinet (model MC-DD900-GY, unbranded) presents a clean, understated rectangular silhouette defined by a consistent matte light gray finish, with a narrow 30mm formed steel frame border framing two equal solid door panels fitted with streamlined brushed nickel-plated recessed pulls. A keyed cam lock sits positioned on the right door, securing both panels simultaneously when engaged, while the cabinet’s flat integrated base and pre-drilled rear mounting points allow flexible placement in either desktop or wall-mounted orientations without disrupting visual flow in occupied spaces. Constructed primarily from cold-rolled steel finished with a durable epoxy polyester powder coating, the cabinet features hemmed and folded edges on all exposed panels to eliminate sharp contact points, paired with zinc-plated steel concealed hinges, zinc alloy lock hardware, and galvanized steel wall-mounting brackets with concrete-appropriate expansion bolts. The interior holds one removable steel shelf with reinforced folded edges, supported by zinc-plated clips that fit into vertical frame holes spaced to allow flexible repositioning for varied storage needs. An integrated rsed base mntns a small clearance from supporting surfaces to reduce moisture contact with the cabinet bottom, while the sealed non-porous coating resists scratches, common cleaning solutions, oil, and dust accumulation for long-term aesthetic and functional retention. Practical design elements include outward-opening doors that allow full, unobstructed access to internal storage space, an adjustable locking mechanism supplied with two identical keys, adjustable hinge hardware to mntn flush door alignment even on uneven mounting surfaces, and included anti-tip anchors to prevent forward tipping when doors are fully opened and loaded. The shelf supports stable distributed weight loads suitable for light-duty storage use, while hinges and locking components are engineered to withstand repeated dly operation over extended service life. This cabinet fits a broad range of commercial and residential settings. It works well in office workstations, positioned under desks or on credenzas to hold documents, supplies, and small equipment; in workshops, wall-mounted to organize tools and maintenance parts; in healthcare and lab spaces, to store PPE and testing supplies thanks to its disinfection-friendly surface; in residential home offices and craft rooms, to organize files and household items while securing sensitive materials; in retl back-of-house areas, for small inventory and supply storage with wide door access for quick restocks; and in educational facilities, where its rounded safe edges and scratch-resistant surface suit frequent staff and student use. For procurement, buyers should note the cabinet ships in protective packaging suitable for standard freight loading, with assembly time appropriate for single-person installation. Bulk order planning can leverage stackable packaging for efficient contner loading, and purchasers should confirm final material thickness, coating specifications, and hardware inclusions with suppliers to align with project-specific durability and installation requirements, particularly when selecting wall-mounted placement to match wall substrate conditions.
