Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 400 x 1850 mm | |
|---|---|---|
| Interior shelf quantity | 4 | |
| Shelf thickness | 25 mm | |
| Door glass panel thickness | 5 mm | |
| Steel body panel thickness | 0.8 mm | |
| Tier height clearance (maximum shelf spacing) | 420 mm | |
| Base plinth height | 50 mm | |
| Handle length | 120 mm | |
| Door frame width | 60 mm | |
| Back panel thickness | 0.6 mm | |
| Edge band thickness | 1.2 mm | |
| Internal usable width per compartment | 420 mm | |
| Anti-tip wall connector mounting hole spacing | 160 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm |
Net weight / load capacity / users / durability
| Net product weight | 52 kg | |
|---|---|---|
| Uniform distributed load per shelf | 30 kg | |
| Total cabinet static load capacity | 150 kg | |
| Shelf height adjustment increment | 32 mm | |
| Number of adjustable shelf positions | 12 | |
| Door opening angle | 110 degrees | |
| Lock security | Keyed different lock | |
| Recommended service life | 10 years | |
| Surface scratch resistance | 500 cycles | |
| Single shelf load-bearing surface | 860 x 360 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main cabinet frame and panels | 0.8mm thick cold-rolled steel with epoxy polyester powder coat finish, silver matte color | |
|---|---|---|
| Door panels | 5mm thick frosted semi-transparent tempered safety glass set in steel door frames | |
| Interior shelves | 25mm thick reinforced cold-rolled steel shelves, matching powder coat finish | |
| Shelf support rails | 1.2mm thick punched galvanized steel rails, mounted vertically on interior side panels | |
| Door handles | Chrome-plated zinc alloy recessed pull handles, vertically mounted on outer edge of each door | |
| Lock assembly | Zinc alloy keyed cam lock with 2 supplied keys, mounted centrally between doors | |
| Door hinges | Cold-rolled steel concealed butt hinges, 2 hinges per door | |
| Base plinth | 1.0mm thick folded cold-rolled steel, fully welded to cabinet bottom | |
| Surface treatment | Acid-washed, phosphated pre-treatment prior to powder coating | |
| Back panel | 0.6mm thick cold-rolled steel sheet, spot-welded to rear cabinet frame with folded edge reinforcements | |
| Anti-tip hardware | 1.5mm thick steel L-bracket with included wall screws, 2 brackets supplied per cabinet | |
| Door gaskets | 0.8mm thick EPDM foam gaskets fitted along door inner perimeter |
Adjustment / rotation / tilt / mobility / storage features
| Adjustable shelf configuration | Shelves can be repositioned along full interior height at 32mm increments to accommodate items of varying heights from small office supplies to tall binders | |
|---|---|---|
| Centralized locking | Single key lock located at the middle door stile secures both doors simultaneously, preventing unauthorized access to stored contents | |
| Semi-transparent content screening | Frosted glass doors obscure clear views of stored items to reduce visual clutter in workspace, while allowing ambient light to pass into cabinet interior | |
| Freestanding installation | Cabinet requires no wall fixing for standard use, can be placed directly on level office floors against walls or as a room divider accessory | |
| Moisture protection | Raised 50mm base plinth elevates the lowest storage shelf above floor level, preventing contact with minor floor spills or cleaning moisture | |
| Quiet door operation | Concealed hinges are fitted with nylon washers to reduce metal-on-metal friction, eliminating squeaking during regular door opening and closing | |
| Leveling compatibility | Pre-drilled holes in base plinth accept optional adjustable glides for installation on uneven floor surfaces | |
| Anti-tip safety retention | Included steel L-brackets secure the top rear of the cabinet to wall studs, preventing forward tipping when doors are fully opened or heavily loaded shelves are extended | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 | |
|---|---|---|
| Shipping carton dimensions | 960 x 460 x 1920 mm | |
| Gross shipping weight | 58 kg | |
| Shipping volume per unit | 0.85 CBM | |
| On-site assembly time | 20 minutes | |
| 20ft GP container loading quantity | 28 units | |
| 40ft HQ container loading quantity | 70 units | |
| Standard packaging materials | 5-layer double-wall corrugated carton, expanded polystyrene corner protectors, polyethylene stretch wrap, plastic hardware bag | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Open-plan office storage | Suitable for placement along office walls to store documents, office supplies and reference materials, with frosted glass doors maintaining a tidy professional appearance | |
|---|---|---|
| Medical or laboratory storage | Smooth powder coated steel and glass surfaces are easy to clean and disinfect, suitable for storing non-critical supplies in clinic or clean office environments | |
| Home office and study use | Neutral silver finish complements modern home interiors, provides lockable storage for files, books and personal items without appearing overly industrial | |
| School and educational facility use | Durable steel construction and lockable doors support long-term use in staff rooms, administrative offices and library storage areas for documents and teaching materials | |
| Retail back-of-house storage | Provides secure visible storage for retail supplies, paperwork and operational materials in stock rooms or staff areas | |
| Recommended companion products | Pairs with standard office desks, task chairs and lateral filing cabinets to create coordinated office storage and workspace systems |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture - Part 2: Safety requirements, applicable to structural safety, edge finishing and load stability verification | |
|---|---|---|
| EN 14074:2004 | Office furniture - Storage units and work surfaces - Test methods for strength and durability, applicable to cyclic load testing of shelves and doors |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture, applicable to dimensional tolerance, coating adhesion and structural stability inspection for this steel storage cabinet | |
|---|---|---|
| GB/T 4893.8-2013 | Surface wear resistance test for furniture surfaces, applicable to powder coated steel surface durability verification | |
| GB 15763.2-2005 | Safety requirements for tempered glass used in furniture, applicable to impact resistance and breakage safety verification of door glass panels | |
| GB/T 10357.5-2011 | Furniture mechanical performance test for storage units, applicable to shelf load capacity, door durability and structural stability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture, applicable to dimensional tolerance, coating adhesion and structural stability inspection for this steel storage cabinet; 2. GB/T 4893.8-2013: Surface wear resistance test for furniture surfaces, applicable to powder coated steel surface durability verification; 3. GB 15763.2-2005: Safety requirements for tempered glass used in furniture, applicable to impact resistance and breakage safety verification of door glass panels; 4. GB/T 10357.5-2011: Furniture mechanical performance test for storage units, applicable to shelf load capacity, door durability and structural stability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
