Automatic mm / inch conversion · Core engineering specifications
| Overall cabinet dimensions | 900 x 400 x 1020 mm | |
|---|---|---|
| Single drawer internal dimensions | 390 x 340 x 120 mm | |
| Right door compartment internal dimensions | 390 x 360 x 940 mm | |
| Cabinet side/back panel steel thickness | 0.6 mm | |
| Drawer front panel steel thickness | 0.8 mm | |
| Door panel steel thickness | 0.8 mm | |
| Handle protrusion from front surface | 25 mm | |
| Adjustable shelf inside door compartment thickness | 0.7 mm | |
| Drawer slide clearance between closed drawer and cabinet body | 2 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Total cabinet net weight | 48 kg | |
|---|---|---|
| Per-drawer static load capacity | 25 kg | |
| Drawer open/close cycle durability | 50000 cycles | |
| Door hinge open/close cycle durability | 80000 cycles | |
| Powder coating surface abrasion resistance | 2000 rub cycles | |
| Anti-tip connector load rating | 50 kg | |
| Lock mechanism cycle durability | 10000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Cabinet main frame (top, sides, base) | Cold-rolled steel sheet with light gray epoxy-polyester powder coat | |
|---|---|---|
| Drawer boxes and fronts | 0.8mm thick cold-rolled steel with matching powder coat finish | |
| Right-side door panel | 0.8mm thick cold-rolled steel with matching powder coat finish | |
| Drawer and door pull handles | Zinc-alloy with brushed satin nickel finish | |
| Lock assemblies | Steel cam locks with two keys per lock, chrome-plated cylinder | |
| Drawer slides | 3-section full-extension cold-rolled steel ball bearing slides, zinc-plated for corrosion resistance | |
| Door hinges | Concealed steel butt hinges with brass pivot pins | |
| Internal adjustable shelves | 0.7mm thick cold-rolled steel with powder coat finish, fitted with metal shelf support clips | |
| Feet/base pads | High-density PVC anti-slip leveling pads | |
| Cabinet main carcass (top, sides, base, vertical divider) | 0.6mm thick cold-rolled steel sheet with light gray matte epoxy-polyester powder coat, folded hem construction on all exposed edges | |
| Cabinet rear back panel | 0.5mm thick cold-rolled steel sheet with matching powder coat, spot-welded to carcass frame | |
| Drawer assemblies (front, box, rear panel) | 0.8mm thick cold-rolled steel with matching powder coat, integrated recessed handle mounting points |
Adjustment / rotation / tilt / mobility / storage features
| 6 independent full-extension drawers | Left column drawers extend fully via ball bearing slides, provide divided small-item storage for documents, supplies or parts | |
|---|---|---|
| 1 lockable full-height door compartment | Right section features a key-locked door enclosing adjustable shelves for larger items, binders or bulk office supplies | |
| Independent top drawer/frame lock | Key lock at top left of cabinet frame locks all 6 drawers simultaneously to prevent unauthorized access | |
| Adjustable shelf positioning in door compartment | 4 shelf support positions allow shelf height adjustment in 50mm increments to accommodate items of varying heights | |
| Smooth drawer operation with positive stop | Drawers include built-in stop to prevent accidental full pull-out when fully extended, reducing risk of drawer drop or contents spill | |
| Door opening angle limit | Door opens to 110 degrees for full access to internal shelf space, with hinge stop to prevent over-swing and wall damage | |
| Anti-scratch surface protection | Powder coat finish resists daily scuffs, stains and minor impacts, suitable for regular office use | |
| Leveling adjustment | Base pads allow 5mm height adjustment to compensate for uneven floor surfaces, ensuring cabinet sits stable without rocking | |
| Lock cylinder mounting diameter | 18 mm | |
| Centralized drawer column lock | Key lock at top left of cabinet frame locks all 6 drawers simultaneously with a single key turn, eliminating the need for individual drawer locks | |
| Scratch and stain resistant surface | Epoxy-polyester powder coat finish resists daily scuffs, liquid stains and minor impact damage, wipe-clean with standard office cleaning products | |
| Anti-tip safety restraint | Included steel wall anchor bracket secures the cabinet rear to adjacent wall studs, preventing forward tipping when multiple drawers are fully extended with loaded contents |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 unit per carton | |
|---|---|---|
| Shipping carton dimensions | 940 x 440 x 1060 mm | |
| Gross shipping weight per carton | 53 kg | |
| Shipping volume per unit | 0.44 CBM | |
| Required assembly time | 20 minutes | |
| 20ft GP container loading quantity | 72 units | |
| 40ft HQ container loading quantity | 176 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split |
Recommended spaces / users / usage modes
| Small office record keeping | Suitable for admin, accounting or HR teams to organize paper files, forms and archived records in a compact footprint | |
|---|---|---|
| Workshop or lab small parts storage | Drawers can be used to sort tools, fasteners, lab supplies or small components, with the door compartment holding larger equipment | |
| Healthcare clinic supply storage | Lockable sections can store medical supplies, forms or consumables in examination rooms or admin areas, with easy-to-clean powder coat surface | |
| Home office organization | Compact size fits in home office spaces to organize paperwork, office supplies and personal items without occupying excessive floor space | |
| Administrative office record storage | Suitable for admin, HR and accounting teams to organize paper files, forms, office supplies and archived records in a compact under-counter or standalone footprint; lockable sections meet basic document security requirements for non-confidential records | |
| Healthcare clinic supply organization | Lockable compartments can store medical forms, exam supplies or non-controlled consumables in exam rooms or clinic admin areas; smooth non-porous powder coat finish supports regular disinfection and cleaning protocols | |
| Education staff room storage | Suitable for school staff rooms to store grading materials, classroom supplies, student records and personal items; light gray neutral finish matches standard institutional furniture schemes | |
| Retail back-of-house storage | Can be used in retail stock rooms to store store supplies, price tags, transaction records and small inventory items; steel construction withstands regular use in high-traffic back-of-house environments |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Applicable European standard for office storage furniture, specifies safety requirements for strength, durability and stability of freestanding storage cabinets | |
|---|---|---|
| EN 10346:2015 | Applicable material standard for continuously hot-dip coated cold-rolled steel sheet used in furniture construction, specifies material performance requirements | |
| EN 13150:2019 | European workroom storage furniture standard, specifies stability and load performance requirements for cabinets used in workshop or lab environments; recommended for non-office commercial application orders, subject to third-party test report verification |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Applicable North American standard for storage furniture, specifies performance and durability testing requirements for drawers, doors, shelves and locking mechanisms for commercial office use |
|---|
Standards applicable to China-market projects
| GB/T 3327-2017 | Applicable standard for metal office storage furniture, specifies dimensional tolerances, load capacity requirements and structural stability testing requirements for filing and storage cabinets | |
|---|---|---|
| GB/T 13667.1-2015 | Applicable standard for steel office furniture, includes general technical requirements for surface finish, hardware performance and structural durability | |
| GB 18584-2001 | Applicable environmental standard for furniture, sets limits for formaldehyde and heavy metal emissions from surface coatings, suitable for indoor office use | |
| GB/T 19536-2004 | Metal furniture surface coating performance standard, specifies requirements for coating hardness, abrasion resistance and corrosion resistance; recommended as procurement acceptance criteria, subject to third-party test report verification |
This product must meet the following technical requirements: 1. GB/T 3327-2017: Applicable standard for metal office storage furniture, specifies dimensional tolerances, load capacity requirements and structural stability testing requirements for filing and storage cabinets; 2. GB/T 13667.1-2015: Applicable standard for steel office furniture, includes general technical requirements for surface finish, hardware performance and structural durability; 3. GB 18584-2001: Applicable environmental standard for furniture, sets limits for formaldehyde and heavy metal emissions from surface coatings, suitable for indoor office use; 4. GB/T 19536-2004: Metal furniture surface coating performance standard, specifies requirements for coating hardness, abrasion resistance and corrosion resistance; recommended as procurement acceptance criteria, subject to third-party test report verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
