Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 400 x 1800 mm | |
|---|---|---|
| Upper door compartment internal height | 850 mm | |
| Single upper door width | 440 mm | |
| Drawer bank height | 900 mm | |
| Single drawer external dimensions | 420 x 340 x 140 mm | |
| Drawer internal usable depth | 320 mm | |
| Handle length | 100 mm | |
| Base plinth height | 50 mm | |
| Steel frame and panel thickness | 0.7 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Net weight per unit | 78 kg | |
|---|---|---|
| Upper compartment static load capacity | 60 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Lock security grade | Keyed cam lock, 200 unique key combinations | |
| Drawer extension travel | 320 mm | |
| Net unit weight | 78 kg | |
| Drawer slide durability rating | 50000 open/close cycles | |
| Lock key combination count | 200 unique combinations | |
| Powder coating salt spray resistance | 48 hours | |
| Anti-tip anchoring load rating | 100 kg pull force |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main cabinet body panels | 0.7mm cold-rolled steel, light gray epoxy powder coating | |
|---|---|---|
| Upper cabinet doors | 0.7mm cold-rolled steel, matching powder coating, reinforced inner flanging | |
| Drawer fronts and bodies | 0.6mm cold-rolled steel, matching powder coating, welded corner construction | |
| Door and drawer handles | Brushed finish stainless steel pull handles, 2-point screw fixing | |
| Lock mechanism | Zinc alloy cam lock with 2 brass keys, fitted to upper right door | |
| Drawer slides | Cold-rolled steel ball-bearing 3-section slides, zinc plated | |
| Internal shelf (upper compartment) | 1 adjustable 0.7mm steel shelf, 4-position height adjustment | |
| Base plinth | 1.0mm cold-rolled steel, welded to cabinet frame | |
| Surface coating performance | Epoxy polyester powder coating, salt spray resistance 48 hours | |
| Main cabinet carcass panels | 0.7mm cold-rolled steel, matte light gray epoxy polyester powder coating, welded seam construction, 60um coating thickness | |
| Locking mechanism | Zinc alloy cam lock with 2 brass keys, vertical connecting rod linkage for upper double doors | |
| Upper compartment internal shelf | 0.7mm cold-rolled steel, matching powder coating, 4-position height adjustment |
Adjustment / rotation / tilt / mobility / storage features
| Upper door lock function | Keyed cam lock actuates vertical rods to secure both upper doors, prevents unauthorised access to bulk storage | |
|---|---|---|
| Drawer operation | 12 independent drawers operate on 3-section ball-bearing slides, open to 320mm travel for full access to contents | |
| Upper shelf adjustment | 1 adjustable shelf in upper compartment, adjust to 4 height positions at 50mm increments to accommodate tall or short items | |
| Door opening angle | Upper doors open 110 degrees to fully expose upper compartment interior, fitted with door stop to prevent over-swing | |
| Drawer retention | Each drawer fitted with anti-tip stop to prevent full pull-out and accidental spillage of contents | |
| Storage capacity function | Upper compartment stores bulk files, supplies or oversized items, 12 lower drawers provide sorted, indexed storage for A4 documents, small parts or sample materials | |
| Floor levelling | 4 adjustable levelling feet fitted to base corners, adjust 10mm to compensate for uneven floor surfaces | |
| Lock cylinder diameter | 18 mm | |
| Upper compartment locking | Keyed cam lock actuates 2 vertical steel rods to secure both upper doors simultaneously, preventing unauthorized access to bulk stored items | |
| Upper shelf adjustability | 1 adjustable steel shelf in upper compartment, can be repositioned to 4 height positions at 50mm increments to accommodate items of varying height from documents to tall supply boxes | |
| Upper door operation | Double upper doors open to 110 degrees, fitted with rubber door stops to prevent over-swing and wall impact, providing unobstructed access to the full upper compartment width | |
| Storage organization | Upper lockable compartment provides bulk storage for large files and office supplies, while 12 lower drawers support labeled, sorted storage of A4 documents, small parts, or sample materials |
Verified carton / gross weight / assembly / loading data
| Number of packages | 1 | |
|---|---|---|
| Shipping carton dimensions | 970 x 470 x 1850 mm | |
| Gross shipping weight | 88 kg | |
| Shipping volume per unit | 0.85 CBM | |
| Assembly time | 30 minutes | |
| 20ft GP container loading quantity | 24 units | |
| 40ft HQ container loading quantity | 62 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split |
Recommended spaces / users / usage modes
| General office storage | Suitable for administrative offices, HR and finance departments to store archived documents, files and office supplies, lockable upper section secures confidential materials | |
|---|---|---|
| Medical and clinic storage | Ideal for clinics, dental practices and laboratories to store medical supplies, sample containers and patient records, easy-to-clean powder coated surface resists disinfectant wipes | |
| Workshop and parts storage | Suitable for maintenance workshops and production facilities to store small hardware parts, tools and consumables, individual drawers allow labelled sorting of components | |
| School and institutional storage | Applicable for school administration offices, libraries and government facilities to store records, forms and educational materials, durable steel construction withstands high-frequency use | |
| Archive room storage | Suitable for central archive rooms to store historical records and documents, compact footprint maximises storage capacity per square meter of floor space | |
| General office administrative storage | Suitable for corporate administrative, HR, and finance departments to store archived documents, files, and office supplies, lockable compartments secure confidential materials | |
| Workshop and maintenance parts storage | Suitable for maintenance workshops and production facilities to store small hardware components, tools, and consumables, individual drawers allow labeled sorting of high-volume small parts | |
| School and public sector storage | Applicable for school administration offices, libraries, and government facilities to store records, forms, and educational materials, durable steel construction withstands high-frequency public use |
EU Market Access Requirements* EN Standards
| Office storage safety standard | EN 14073:2004 Office furniture - Storage furniture - Part 2: Safety requirements | |
|---|---|---|
| Surface durability standard | EN 12720:2009 Furniture - Assessment of surface resistance to cold liquids | |
| Storage furniture safety standard | EN 14073:2004 Office furniture - Storage furniture - Part 2: Safety requirements | |
| Hardware durability standard | EN 15338:2007 Furniture hardware - Durability of locks and locking devices |
Standards applicable to China-market projects
| Steel cabinet structural standard | GB/T 13667.1 General technical requirements for steel office furniture | |
|---|---|---|
| Coating environmental standard | GB 18584 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | |
| Steel furniture structural standard | GB/T 13667.1 General technical requirements for steel office furniture | |
| Coating safety standard | GB 18584 Indoor decorating and refurbishing materials - Limit of harmful substances | |
| Furniture mechanical safety standard | GB/T 10357.5 Test of mechanical properties of furniture - Part 5: Storage furniture |
This product must meet the following technical requirements: 1. Steel cabinet structural standard: GB/T 13667.1 General technical requirements for steel office furniture; 2. Coating environmental standard: GB 18584 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture; 3. Steel furniture structural standard: GB/T 13667.1 General technical requirements for steel office furniture; 4. Coating safety standard: GB 18584 Indoor decorating and refurbishing materials - Limit of harmful substances; 5. Furniture mechanical safety standard: GB/T 10357.5 Test of mechanical properties of furniture - Part 5: Storage furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
