Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1240 x 350 x 1800 mm | |
|---|---|---|
| Number of compartments | 32 units | |
| Single compartment internal dimensions | 280 x 320 x 200 mm | |
| Steel frame wall thickness | 0.8 mm | |
| Steel door panel thickness | 0.8 mm | |
| Ventilation slot area per door | 1200 mm² | |
| ID card slot size per door | 80 x 40 mm | |
| Handle length per door | 90 mm | |
| Base plinth height | 80 mm | |
| Compartment partition thickness | 0.6 mm | |
| Door overlap clearance | 2 mm | |
| Rear panel thickness | 0.6 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Unit net weight range | 85 kg | |
|---|---|---|
| Static load per compartment | 15 kg | |
| Total unit static load capacity | 480 kg | |
| Lock mechanism cyclic durability | 10000 operations | |
| Door hinge cyclic durability | 50000 open/close cycles | |
| Powder coating surface abrasion resistance | 2000 cycles | |
| Recommended maximum user count | 32 people | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main cabinet frame | Cold-rolled steel sheet, epoxy-polyester powder coated light gray finish | |
|---|---|---|
| Individual compartment doors | Cold-rolled steel sheet with integrated vertical pull handle, punched ventilation slots, recessed card holder | |
| Internal partitions | Cold-rolled steel vertical and horizontal dividers creating separate enclosed compartments | |
| Door locks | Zinc alloy coded combination cam locks with keypad interface | |
| Door hinges | Steel pin hinges welded to door and frame, concealed internal mounting | |
| Rear panel | Cold-rolled steel sheeting fixed to frame with spot welds | |
| Base plinth | Folded cold-rolled steel channel forming a raised stable base | |
| Surface finish | Electrostatic epoxy-polyester powder coat, matte light gray | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Individual compartment locking | Each door secures with an independent coded cam lock, allowing private access for assigned users | |
|---|---|---|
| Door ventilation | 12 punched rectangular slots on the lower section of each door allow air circulation to prevent odor buildup for stored items | |
| User identification | Recessed clear card holder on upper section of each door accepts standard ID labels or name cards for quick compartment assignment | |
| Door operation | Recessed vertical pull handle allows full 180-degree door swing for unobstructed access to compartment contents | |
| Floor mounting capability | Pre-punched holes in the base plinth allow secure anchoring to concrete or raised floors to prevent cabinet tipping | |
| Knockdown assembly | Flat-pack construction with bolted frame connections allows on-site assembly without specialized welding tools | |
| Moisture protection | Raised 80mm base plinth lifts compartment bottoms above floor level to prevent contact with spilled liquids or floor cleaning moisture | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 3 cartons | |
|---|---|---|
| Largest carton dimensions | 1270 x 380 x 120 mm | |
| Total shipping gross weight | 95 kg | |
| Total shipping volume | 0.21 CBM | |
| On-site assembly time | 90 minutes | |
| 20ft GP container loading quantity | 130 units | |
| 40ft HQ container loading quantity | 320 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set |
Recommended spaces / users / usage modes
| Factory employee changing areas | Provides secure individual storage for personal items, work gear and small tools for shift workers in manufacturing facilities | |
|---|---|---|
| Office staff storage zones | Stores personal bags, electronic devices and office supplies for employees in open-plan workspaces with no dedicated desk storage | |
| School and university campus facilities | Serves as day-use storage for students in libraries, gymnasiums and classroom buildings to secure books and personal items during sessions | |
| Public venue temporary storage | Provides secure short-term storage for visitors at gyms, swimming pools, exhibition halls and transport hubs | |
| Hospital staff areas | Stores personal effects and uniform items for clinical and administrative staff in healthcare facilities |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office furniture - Storage furniture - Part 2: Safety requirements | |
|---|---|---|
| EN 14073-3:2004 | Office furniture - Storage furniture - Part 3: Test methods for stability and strength |
Standards applicable to China-market projects
| GB/T 3327-2017 | Metal furniture - General technical requirements for storage cabinets | |
|---|---|---|
| GB/T 13667.1-2015 | Steel furniture - General specification for cabinets and lockers | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture |
This product must meet the following technical requirements: 1. GB/T 3327-2017: Metal furniture - General technical requirements for storage cabinets; 2. GB/T 13667.1-2015: Steel furniture - General specification for cabinets and lockers; 3. GB 18584-2001: Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
