Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 400 x 1800 mm | |
|---|---|---|
| Upper glass door section height | 850 mm | |
| Middle drawer section height | 250 mm | |
| Lower solid door section height | 700 mm | |
| Tempered glass panel thickness | 5 mm | |
| Single drawer internal dimensions | 400 x 350 x 200 mm | |
| Adjustable shelf thickness | 20 mm | |
| Shelf adjustment pitch | 25 mm | |
| Internal usable width | 820 mm | |
| Internal usable depth | 360 mm | |
| Door panel thickness | 25 mm | |
| Side panel thickness | 1 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Total cabinet weight | 75 kg | |
|---|---|---|
| Uniform distributed shelf load capacity | 40 kg | |
| Total cabinet storage capacity | 420 L | |
| Recommended maximum static total load | 200 kg | |
| Lock durability cycle rating | 10000 cycles | |
| Door hinge cycle rating | 50000 cycles | |
| Maximum static total cabinet load | 200 kg | |
| Drawer slide cycle rating | 40000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Cabinet body and frame | 304 food/medical grade brushed stainless steel, 1 mm sheet thickness, welded and polished corners | |
|---|---|---|
| Upper door panels | 5mm frosted tempered safety glass set in stainless steel door frames | |
| Lower door and drawer front panels | Matching brushed stainless steel sheets with reinforced internal backing | |
| Handles | Chrome-plated stainless steel recessed pull handles, bolt-fixed to door and drawer fronts | |
| Lock cylinders | Brass core cam locks with 2 keys per lockable compartment, chrome-plated finish | |
| Internal adjustable shelves | Stainless steel shelves with anti-tilt brackets mounted on vertical slotted rack rails | |
| Drawer slides | Cold-rolled steel three-section full extension ball bearing slides, zinc-plated for corrosion resistance | |
| Door hinges | Stainless steel concealed heavy-duty hinges, 180 degree opening angle | |
| Feet/base | Integrated welded stainless steel kick plinth base, leveler adjustment points at corners | |
| Cabinet base | Integrated welded stainless steel kick plinth base, with adjustable stainless steel leveler feet at four corners | |
| Back panel | 0.8 mm thick stainless steel sheet, spot-welded to cabinet frame with sealed seams | |
| Edge treatment | All exposed metal edges deburred and polished to 0.8 mm radius, no sharp edges |
Adjustment / rotation / tilt / mobility / storage features
| Compartment locking | Three independent locking zones: upper glass doors, two middle drawers, lower solid doors, each operated by separate key lock | |
|---|---|---|
| Shelf adjustability | Two adjustable shelves in upper glass compartment, adjustable on 25mm increments along vertical rails to accommodate varying height supplies | |
| Drawer access | Two equal-width full-extension drawers between upper and lower compartments, suitable for storing small medical instruments, documents or consumables | |
| Door opening | All four doors open outward to 180 degrees, creating full unobstructed access to internal storage spaces | |
| Hygienic cleaning access | Smooth seamless stainless steel surfaces with no recessed dirt traps, suitable for daily disinfection with standard medical cleaning agents | |
| Internal storage split | Upper glass section for visible, frequently accessed supplies; middle drawers for small, high-value items; lower solid section for bulk, less frequently accessed storage | |
| Anti-tilt protection | Integrated anti-tilt brackets prevent more than one drawer being opened at a time, reducing tip-over risk in high-traffic areas | |
| Internal storage zoning | Upper glass section for visible, frequently accessed supplies; middle drawers for small, high-value or sharp items; lower solid section for bulk, less frequently accessed storage | |
| Leveling adjustment | Four corner leveler feet provide 15 mm of vertical adjustment to compensate for uneven floor surfaces, maintaining cabinet plumb for proper door and drawer alignment | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 | |
|---|---|---|
| Shipping carton dimensions | 950 x 450 x 1850 mm | |
| Gross shipping weight | 85 kg | |
| Shipping volume per unit | 0.79 CBM | |
| Assembly time on site | 15 minutes | |
| 20ft GP container loading capacity | 28 units | |
| 40ft HQ container loading capacity | 72 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split |
Recommended spaces / users / usage modes
| Hospital/clinic supply rooms | Suitable for storing sterile supplies, dressings, medical documents and small instruments, with lockable zones to control access to restricted items | |
|---|---|---|
| Laboratory storage areas | Corrosion-resistant stainless steel construction withstands regular chemical cleaning, ideal for storing lab consumables and glassware | |
| Cleanroom and sterile environments | Seamless welded construction has no particle-trapping gaps, compatible with ISO 8 cleanroom cleaning protocols | |
| Office document and archive storage | Durable metal construction supports heavy archive file storage, with glass upper doors to allow quick visual identification of stored files | |
| Pharmacy dispensary storage | Separate locked compartments allow secure storage of controlled medications alongside general pharmaceutical supplies | |
| ISO 8 cleanroom environments | Seamless welded construction has no particle-trapping gaps, compatible with standard cleanroom cleaning and disinfection procedures without shedding particulate | |
| Clinic administrative areas | Durable metal construction supports heavy archive file and office supply storage, with upper glass doors to allow quick visual identification of frequently accessed documents |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Applicable European standard for office and institutional storage furniture, specifies safety and strength requirements for freestanding storage cabinets | |
|---|---|---|
| EN 10088-2:2014 | Applicable material standard for stainless steel sheet used in cabinet construction, specifies grade and finish requirements for corrosion resistance |
Standards applicable to China-market projects
| GB/T 3323-2017 | Applicable standard for steel furniture storage cabinets, specifies structural stability, load capacity and durability requirements for metal storage units | |
|---|---|---|
| GB/T 4893.9-2013 | Applicable surface performance standard for furniture surfaces, specifies abrasion and corrosion resistance requirements for stainless steel surfaces subject to regular cleaning | |
| GB 18584-2001 | Applicable indoor furniture environmental standard, specifies limits for harmful emissions applicable to any internal non-metal components |
This product must meet the following technical requirements: 1. GB/T 3323-2017: Applicable standard for steel furniture storage cabinets, specifies structural stability, load capacity and durability requirements for metal storage units; 2. GB/T 4893.9-2013: Applicable surface performance standard for furniture surfaces, specifies abrasion and corrosion resistance requirements for stainless steel surfaces subject to regular cleaning; 3. GB 18584-2001: Applicable indoor furniture environmental standard, specifies limits for harmful emissions applicable to any internal non-metal components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
