Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 400 x 1800 mm | |
|---|---|---|
| Upper sliding door section height | 800 mm | |
| Lower storage section height | 1000 mm | |
| Single upper frosted glass panel dimension | 520 x 700 mm | |
| Adjustable shelf depth in upper section | 360 mm | |
| Single middle drawer internal dimension | 320 x 340 x 100 mm | |
| Lower side door internal compartment width | 380 mm | |
| Handle length for solid doors and drawers | 100 mm | |
| Base plinth height | 50 mm | |
| Single central drawer internal dimension | 320 x 340 x 100 mm | |
| Cabinet carcass panel thickness | 0.8 mm | |
| Door and drawer front panel thickness | 1.0 mm | |
| Back panel thickness | 0.6 mm | |
| Upper compartment shelf thickness | 0.8 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm |
Net weight / load capacity / users / durability
| Net weight | 95 kg | |
|---|---|---|
| Total static load capacity | 300 kg | |
| Single adjustable shelf static load | 40 kg | |
| Single drawer static load | 20 kg | |
| Lower side compartment shelf load | 50 kg | |
| Lock system load resistance | 500 N lateral force | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating | 100000 cycles | |
| Door hinge opening angle | 110 degrees | |
| Anti-tip anchor load rating | 1000 N pull force |
Core acceptance fields · Panels / hardware / frame / upholstery
| Cabinet body panels | 0.8mm thick 201 grade stainless steel sheet, brushed surface finish | |
|---|---|---|
| Upper door panels | 5mm thick frosted semi-opaque tempered safety glass, set in stainless steel door frames | |
| Door and drawer frames | 1.0mm thick stainless steel bent and welded construction, seamless edge treatment | |
| Hardware handles | Brushed 304 stainless steel pull handles, bolt-fixed to door and drawer fronts | |
| Lock cylinders | Zinc alloy keyed cam locks, separate locks for upper section, left lower door and right lower door | |
| Drawer slides | Cold rolled steel 3-section full extension ball bearing slides, zinc plated finish | |
| Adjustable shelf brackets | Stamped stainless steel shelf supports, 4 points per shelf | |
| Base plinth | 1.2mm thick stainless steel welded base frame, leveler feet at four corners | |
| Back panel | 0.6mm thick cold rolled steel sheet, spot welded to carcass rear frame for structural rigidity | |
| Edge protection | 0.5mm thick PVC edge banding on all exposed cut metal edges, bonded with hot melt adhesive to prevent sharp edges | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Upper door operation | Horizontal sliding glass doors, central lock secures both doors simultaneously to prevent unauthorized access to upper storage | |
|---|---|---|
| Upper shelf adjustment | 2 adjustable shelves per upper door compartment, adjustable on 50mm vertical increments to accommodate items of varying height | |
| Central drawer storage | 6 vertically stacked equal-size drawers, fully extendable for sorted small item, document or supply storage, no integrated lock on individual drawers | |
| Lower compartment storage | Two side hinged solid doors, each enclosing a single fixed shelf for bulkier items, each door fitted with independent key lock for secure separate storage | |
| Surface corrosion resistance | Brushed stainless steel finish resists water, disinfectant and routine cleaning, suitable for hygiene-sensitive environments | |
| Leveling adjustment | 4 adjustable threaded feet at base corners, adjust up to 15mm to compensate for uneven floors | |
| Anti-tip protection | 2 steel anti-tip wall connectors included, installed at upper rear of cabinet to secure to wall studs and prevent forward tipping when drawers/doors are fully extended | |
| Lock operation | Keyed alike option available for multi-cabinet deployments, standard configuration includes unique keys per lock point for compartmentalized access control | |
| Corrosion resistance | Epoxy powder coated finish resists water, routine cleaning chemicals and surface rust for 5 years under normal indoor office use | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Number of packages | 1 | |
|---|---|---|
| Packaging carton dimensions | 1280 x 480 x 1880 mm | |
| Packaged gross weight | 115 kg | |
| Packaged volume | 1.16 CBM | |
| Assembly time required | 15 minutes | |
| 20ft GP container loading capacity | 18 units | |
| 40ft HQ container loading capacity | 45 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split |
Recommended spaces / users / usage modes
| Office document storage | Suitable for general office back-of-house storage, with glass upper section for frequent reference materials and locked lower section for confidential documents | |
|---|---|---|
| Medical and clinic storage | Suitable for hospital, clinic and laboratory supply storage, with stainless steel surface that tolerates regular disinfection and cleaning | |
| Cleanroom and workshop storage | Suitable for industrial workshop, cleanroom or utility room storage of tools, parts and safety supplies, resistant to moisture and minor corrosion | |
| Archive and records room use | Suitable for long-term paper record storage, with adjustable shelves and multiple storage zones to sort documents by access frequency | |
| Restaurant and commercial kitchen storage | Suitable for back-of-house dry storage in commercial food service areas, with non-porous surface that is easy to wipe clean | |
| Medical clinic administration storage | Suitable for hospital administrative areas and clinic supply rooms, with smooth powder coated surface that tolerates regular disinfectant wiping without coating damage | |
| Industrial workshop storage | Suitable for factory workshop and utility room storage of tools, parts and safety supplies, resistant to moisture and minor surface impact better than laminate cabinets | |
| Educational facility storage | Suitable for school administration offices, teacher workrooms and classroom supply storage, with durable surface that resists scratches and frequent daily use |
EU Market Access Requirements* EN Standards
| BS EN 14073-2:2004 | Office furniture - Storage furniture, applies to safety and strength requirements for office storage units |
|---|
Standards applicable to China-market projects
| GB/T 13668-2015 | Steel storage cabinets for office use, applies to dimensional tolerance, structural strength and coating performance requirements for this product category | |
|---|---|---|
| GB/T 3324-2017 | General technical requirements for metal furniture, applies to material thickness, welding quality and edge safety requirements | |
| GB/T 28202-2011 | Hardware for furniture, applies to performance and durability requirements for locks, handles and drawer slides used on this cabinet | |
| GB/T 17657-2013 | Test methods for furniture surface coatings, applies to coating adhesion, hardness and corrosion resistance testing |
This product must meet the following technical requirements: 1. GB/T 13668-2015: Steel storage cabinets for office use, applies to dimensional tolerance, structural strength and coating performance requirements for this product category; 2. GB/T 3324-2017: General technical requirements for metal furniture, applies to material thickness, welding quality and edge safety requirements; 3. GB/T 28202-2011: Hardware for furniture, applies to performance and durability requirements for locks, handles and drawer slides used on this cabinet; 4. GB/T 17657-2013: Test methods for furniture surface coatings, applies to coating adhesion, hardness and corrosion resistance testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
