Automatic mm / inch conversion · Core engineering specifications
| Overall footprint dimensions | 900 x 400 x 1800 mm | |
|---|---|---|
| Per-tier vertical internal height | 340 mm | |
| Single door width | 438 mm | |
| Single door height | 320 mm | |
| Internal compartment depth | 370 mm | |
| Door panel thickness | 1.0 mm | |
| Frame and separator panel thickness | 1.2 mm | |
| Pull handle length | 120 mm | |
| Label holder size | 60 x 40 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Net product weight | 72 kg | |
|---|---|---|
| Static load capacity per compartment | 20 kg | |
| Total usable internal storage volume | 0.53 m³ | |
| Door open angle | 110 degrees | |
| Surface corrosion resistance | 48 hours neutral salt spray resistance | |
| Lock cycle durability | 10000 open/close cycles | |
| Hinge cycle durability | 50000 open/close cycles | |
| Unit static stability tilt angle | 12 degrees | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer cabinet shell | Brushed finish 201 stainless steel, 1.2mm sheet thickness | |
|---|---|---|
| Compartment doors | Brushed 201 stainless steel, 1.0mm sheet thickness, reinforced with folded edge perimeters | |
| Pull handles | Polished 201 stainless steel vertical bar handles, mechanically fastened to door faces | |
| Door locks | Zinc alloy keyed cam locks, keyed different per compartment with 2 keys per lock | |
| Internal compartment shelves | Fixed 1.0mm stainless steel flat panels welded to tier separators | |
| Door hinges | Stainless steel concealed pivot hinges, welded to door and frame for maintenance-free operation | |
| Label holders | Brushed stainless steel welded plates with clear acrylic insert slot | |
| Horizontal tier seams | Folded and spot-welded stainless steel joining flanges, silicone sealed for moisture resistance | |
| Rear cabinet panel | Brushed 201 stainless steel, 0.8mm sheet thickness, spot-welded to cabinet frame flanges | |
| Anti-tip brackets | 1.5mm thick galvanized steel L-brackets, included with concrete and drywall anchor fasteners | |
| Adjustable leveling feet (optional) | M10 threaded stainless steel feet with 20mm adjustment travel, rubber base pad for floor protection | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Individual compartment locking | Each right-side door per tier is fitted with a keyed cam lock that secures both left and right doors on its tier when engaged, preventing unauthorized access to the full tier | |
|---|---|---|
| Compartment identification | A dedicated stainless steel label holder is fitted to the upper right of each lockable door to display compartment number, user name, or content labels | |
| Stacked modular assembly | The cabinet is constructed from 5 separate stacked horizontal sections that are bolted together at installation, allowing flat-pack shipping and easy replacement of damaged tiers | |
| Swing door operation | Each door opens outward to the side (left doors hinged on left edge, right doors hinged on right edge) to provide full unobstructed access to the compartment interior | |
| Smooth edge safety | All door, frame, and panel edges are folded and deburred to eliminate sharp metal edges and reduce laceration risk during use | |
| Surface cleanability | The continuous brushed stainless steel surface has no recessed seams on door faces, allowing wipe-down cleaning with standard disinfectants for hygiene-sensitive environments | |
| Floor-standing installation | The cabinet is designed for free-standing placement on level finished floors, with adjustable optional stainless steel feet available to compensate for uneven floor surfaces | |
| Lock cylinder diameter | 18 mm | |
| Lock cylinder compatibility | 18mm diameter cam lock cylinders are compatible with standard master key systems, allowing facility management override access for all compartments | |
| Wall anti-tip anchoring | Two L-shaped steel brackets secure the top rear of the cabinet to structural wall surfaces, resisting 50kg outward pull force to prevent tip-over during loaded door opening | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 6 | |
|---|---|---|
| Shipping carton dimensions (per largest tier package) | 940 x 440 x 390 mm | |
| Total shipping gross weight | 82 kg | |
| Total shipping volume | 0.76 CBM | |
| On-site assembly time | 60 minutes | |
| 20ft full container load quantity | 36 units | |
| 40ft HQ full container load quantity | 88 units | |
| Standard packaging material | 5-layer double-wall corrugated cartons, 20mm EPS foam edge protection, stretch-wrapped unitized loads for LCL shipments | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Healthcare facility storage | Suitable for hospital, clinic, or cleanroom storage of personal effects, medical supplies, or staff belongings due to non-porous stainless steel surface that supports frequent disinfection | |
|---|---|---|
| Employee personal locker room use | Suitable for factory, laboratory, or office staff changing rooms to provide 10 individual lockable compartments for personal item storage | |
| Food service and commercial kitchen storage | Suitable for back-of-house kitchen storage of utensils, uniforms, or dry goods as stainless steel resists moisture and food residue buildup | |
| Educational institution storage | Suitable for school, university, or training center storage of student supplies, lab materials, or personal items in workshop and lab areas | |
| Clean industrial environment storage | Suitable for electronics manufacturing, pharmaceutical production, or clean production areas where particle shedding from wood or coated steel furniture is restricted | |
| Correctional facility secure storage | Suitable for staff secure storage in correctional or detention facilities, with welded construction and keyed cam locks that resist forced entry for personal item storage in controlled access areas |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture – Part 2: Safety requirements, applicable for structural stability, edge safety, and load capacity verification | |
|---|---|---|
| EN 14074:2004 | Office furniture – Storage furniture – Test methods for the determination of strength and durability, applicable for cyclic door operation and static load testing | |
| EN 10088-2:2014 | Stainless steels – Part 2: Technical delivery conditions for sheet/plate and strip of corrosion resisting steels for general purposes, applicable for verification of stainless steel material grade and thickness |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture, applicable for structural strength, dimensional tolerance, and surface finish acceptance of this steel storage cabinet | |
|---|---|---|
| GB/T 13668-2015 | Requirements for steel storage cabinets, applicable for compartment load rating, lock performance, and door operation durability acceptance | |
| GB 18584-2001 | Limit of harmful substances for indoor furniture, applicable for volatile organic compound and heavy metal content limits for any non-metallic components used in the cabinet | |
| GB/T 10125-2012 | Corrosion testing in artificial atmospheres - Salt spray tests, applicable for verification of stainless steel surface corrosion resistance performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture, applicable for structural strength, dimensional tolerance, and surface finish acceptance of this steel storage cabinet; 2. GB/T 13668-2015: Requirements for steel storage cabinets, applicable for compartment load rating, lock performance, and door operation durability acceptance; 3. GB 18584-2001: Limit of harmful substances for indoor furniture, applicable for volatile organic compound and heavy metal content limits for any non-metallic components used in the cabinet; 4. GB/T 10125-2012: Corrosion testing in artificial atmospheres - Salt spray tests, applicable for verification of stainless steel surface corrosion resistance performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
